Meanwell (NES-350-12) AC/DC 12V Switch Power Supply

Prod Model:	NES-350-12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item No:	Nes-350-12
Rated Power:	350W
Output Voltage:	11.4~13.2V
Rated Current:	850mA
Efficiency:	83%
Input Voltage Range:	90-264VAC
Application:	LED Lighting, CCTV Camera, DVR, Industrial Equipm
Frequency Range:	47~63Hz
Material:	Metal Case
Product Dimension:	215*115*50mm (L*W*H)
Output Type:	Single
Warranty:	>2 Years
Output Power:	301 - 400W
Input Voltage:	Full Range
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	EMC

Product Description

Meanwell (NES-350-12) AC/DC 12V Switch Power Supply

Features:
AC input range selectable by swith
Protections: Short circuit / Overload / Over voltage / Over temperature
Withstand 300VAC Surge input for 5 seconds
forced air Cooling by built-in DC fan
Built-in cooling Fan ON-OFF control
Built-in constant current limiting circuit
Low cost / High reliability
LED indicator for power on
100% full load burn-in test
Fixed switching frequency at 100KHz
2 years warranty


Specification:

MODEL		NES-350-12
OUTPUT	DC VOLTAGE	12V
	CURRENT RANGE	0~29A
	RATED CURRENT	29A
	RATED POWER	348W
	RIPPLE & NOISE (max.) Note.2	150mVp-p
	VOLTAGE ADJ. RANGE	10~13.5V
	VOLTAGE TOLERANCE Note.3	±1.5%
	LINE REGULATION	±0.5%
	LOAD REGULATION	±1.0%
	SETUP, RISE TIME Note.5	1000ms, 50ms/230VAC 1000ms, 50ms/115VAC at full load
	HOLD UP TIME (Typ.)	20ms/230VAC 16ms/115VAC at full load
INPUT	VOLTAGE RANGE Note.5	90 ~ 132VAC / 180 ~ 264VAC by switch 254 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	83%
	AC CURRENT (Typ.)	7A/115VAC 4A/230VAC
	INRUSH CURRENT (Typ.)	40A/115VAC 60A/230VAC
	LEAKAGE CURRENT	<3.5mA / 240VAC
PROTECTION	OVERLOAD	105 ~ 150% rated output power,  Protection type:Constant current limiting, recovers automatically after fault condition is removed
	OVER VOLTAGE	13.8 ~ 16.2V Protection type : Hiccup mode, recovers automatically after fault condition is removed
	OVER TEMPERATURE	90°C±5°C(3.3~7.5V), 85°C±5°C(12V~15V), 80°C±5°C(24V), 75°C±5°C(27V~48V) (TSW1) detect on case Protection type : Hiccup mode, recovers automatically after temperature goes down
FUNCTION	DC OK SIGNAL	RTH2>=50 FAN ON, <=45FAN OFF (3.3 ~ 7.5V) RTH2>=55 FAN ON, <=50 FAN OFF (12 ~ 48V)
ENVIRONMENT	WORKING TEMP.	-20 ~ +60°C (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-20 ~ +85°C , 10 ~ 95% RH
	TEMP. COEFFICIENT	±0.03%/°C(0 ~ 50°C)
	VIBRATION	10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY & EMC	SAFETY STANDARDS	UL60950-1 approved
	WITHSTAND VOLTAGE	I/P-O/P:3KVAC     I/P-FG:2KVAC     O/P-FG:0.5KVAC
	ISOLATION RESISTANCE	I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 °C/ 70% RH
OTHERS	MTBF	234.3K hrs min. MIL-HDBK-217F (25°C)
	DIMENSION	215*115*50mm (L*W*H)
	PACKING	1.07Kg; 12pcs/13.5Kg/0.92CUFT

Applications
Our company-- HongLet can support your needs by the technology you are working on. Whether it is for a specifical need for a Medical Power Supply or just a generic Universal Input Power Supply, we probably have a power supply solution for you.
Other power supply applications and uses include: LED lighting, CCTV Camera, Low noise amplifiers, signal prosessing, data acquisition, sensors, automatic test equipment, laboratory test equipment, control circuits, etc.
