Meanwell Switching Power Supply for LED Lamp

Prod Model:	Nes-150-12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item No:	Nes-150-12
Rated Power:	150W
Output Voltage:	11.4~13.2V
Rated Current:	850mA
Efficiency:	83%
Input Voltage Range:	90-264VAC
Application:	LED Lighting, CCTV Camera, DVR, Industrial Equipm
Frequency Range:	47~63Hz
Material:	Metal Case
Product Dimension:	199*98*38mm (L*W*H)
Output Type:	Single
Warranty:	>2 Years
Output Power:	101 - 200W
Input Voltage:	Full Range
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	EMC

Product Description

Meanwell Nes-150-12 150W 12V Power Supply for LED Strip

Features:

1.150W Single output switching power supply
2. Economical non-PFC models with complete safety certificates (UL/CB/EMC/CCC)
3. Miniature size suitable for varieties of installation conditions
4. Universal AC input/ Full range
5. Complete Protections: Short circuit / Overload / Over voltage / Over temperature
6. Cooling by free air convection
7. LED indicator for power on
8. 100% full load burn-in test
9. 2 years warranty
10.Strong built for heavy duty and long usage performance
11.Wattages from 15~350W switching power supply


Specification

Switching Power Supply		NES-150-12
OUTPUT	DC VOLTAGE	12V
	CURRENT RANGE	0 ~ 12.5A
	RATED CURRENT	12.5A
	RATED POWER	150W
	RIPPLE & NOISE (max.)  Note.2	120mVp-p
	VOLTAGE ADJ. RANGE	11.4 ~ 13.5V
	VOLTAGE TOLERANCE NOTE.3	1.0%
	LINE REGULATION	0.5%
	LOAD REGULATION	0.5%
	SETUP, RISE TIME NOTE.5	800ms, 20ms/230VAC 1200ms, 30ms/115VAC at full load
	HOLD UP TIME (Typ.)	24ms/230VAC 20ms/115VAC at full load
INPUT	VOLTAGE RANGE	90 ~ 132VAC / 180 ~ 264VAC by switch 254 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	83%
	AC CURRENT (Typ.)	3A/115VAC 2A/230VAC
	INRUSH CURRENT (Typ.)	COLD START 45A/230VAC
	LEAKAGE CURRENT	<2mA / 240VAC
PROTECTION	OVER LOAD	110 ~ 150% rated output power
		Protection type : Hiccup mode, recovers automatically after fault condition is removed
	OVER VOLTAGE	13.8 ~ 16.2V
		Protection type : Hiccup mode, recovers automatically after fault condition is removed
ENVIRONMENT	WORKING TEMP.	-20 ~ +60°C (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-40 ~ +85°C , 10 ~ 95% RH
	TEMP. COEFFICIENT	0.03%/°C (0 ~ 50°C )
	VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY &EMC(Note 4)	SAFETY STANDARDS	UL60950-1, TUV EN60950-1 Approved
	WITHSTAND VOLTAGE?	I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	ISOLATION RESISTANCE	I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	EMI CONDUCTION & RADIATION	Compliance to EN55022 (CISPR22) Class B
	HARMONIC CURRENT	Compliance to EN61000-3-2,-3
	EMS  IMMUNITY	Compliance to EN61000-4-2, 3, 4, 5, 6, 8,11, ENV50204, EN55024, EN61000-6-1, heavy industry level, criteria A
OTHERS	MTBF	433.3Khrs min. MIL-HDBK-217F (25 )
	DIMENSION	199*98*38mm (L*W*H)
	PACKING	0.7Kg; 30pcs/22Kg/1.24CUFT
NOTE	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°Cof ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Line regulation is measured from low line to high line at rated load. 5. Load regulation is measured from 0% to 100% rated load. 6. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. 7. Length of set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time.

Applications
Our company-- HongLet can support your needs by the technology you are working on. Whether it is for a specifical need for a Medical Power Supply or just a generic Universal Input Power Supply, we probably have a power supply solution for you.
Other power supply applications and uses include: LED lighting, CCTV Camera, Low noise amplifiers, signal prosessing, data acquisition, sensors, automatic test equipment, laboratory test equipment, control circuits, etc.
