Microwave Motion Sensor

Product Description

It is an active motion detector with adjustable sensitivity, daylight detection and time setting. It's based Doppler principle and RADAR technology, adopting rod antenna & high performance micro-chip. It is easy to install, provide high probability of detection, low nuisance alarms and resistance to rain, fog, wind, dust, falling snow and temperature extremes.
It can be widely used in public places such as corridor, sidewalks, car parking, warehouses and office building etc.

Product specification
1
Operating voltage
220-240V/AC
2
Rated load
800W (Max. Resistive load)
3
400W(Max. Inductive Load)
4
Detection area
2-10 meters
5
Time setting
10sec-12min
6
Light control
2~2000lux
7
Microwave frequency
5.8GHz +/-75MHz
8
Transmission power
<0.2mW
9
Installation
Ceiling mounting, wall installation
10
Detection angle
360°
11
Mounting height
Max. 5 m
12
Operating temperature
-10° C~+60° C
13
Product Size(L*W*H)
43*42*90mm.
