MR-85 5A Ring Type Current Transformer

Name: MR-85 5A Ring Type Current Transformer
Brand: all-electronics-online.com
SKU: 704924575
Availability: InStock
Rating: 4.8 (31 reviews)

Price:	US $ 4.0-4.5/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	500/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	MR-85
Markets:	South America,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Class:	1.0/3.0
Certificate:	IEC185/BS7626
Current Ratio:	30/5A-5000/5A
Maximun Voltage:	0.75kv
Phase:	Single
Type:	Current Transformer

Product Description

MR current transformer series:

Model MR series current transformer are available for connecting with cable, and also available for connecting with bus bar

MR tecnicial specifications:
1. Primary current: 30A-5000A
2. Secondary current: 5A/1A
3. Standard approval: IEC185 BS7626
4. Maximum voltage: 0.72kv
5. Frequency: 50/60Hz
6. Class: 0.5/1.0
7. Rated load: 5VA-15VA
8. Short time thermal current: Ith=60*ih
9. Rated security coefficient: Fs<5

Model	Current ratio (A)	Class 0.5 (VA)	Class 1.0 (VA)
MR-85	600/5	5	10
MR-85	800/5	7.5	10
MR-85	1000/5	10	15
MR-85	1200/5	10	15
MR-85	1500/5	10	15
MR-85	1600/5	10	15

About Maxwel Electric

At Maxwel Electric, we efficiently produce a wide variety of tapes and electrical products. Our factory is ISO 9001: 2000-certified, and our products meet various international standards for easier market entry.

A large range for your selection

You can come to us for self-amalgamating, semi-conducting, butyl, mastic, sealing, PVC and aluminum foil tapes. We also manufacture miniature circuit breakers, residual current circuit breakers, residual current circuit breakers with over-current protection, switch disconnectors, distribution boxes and more.

Contact us

Our factory is equipped with state-of-the-art testing equipment, and we perform inspections during every step of production to ensure quality. To learn more, contact us today.
