Multimode Om3 Sc/Upc Fiber Optic Pigtail

Name: Multimode Om3 Sc/Upc Fiber Optic Pigtail
Brand: all-electronics-online.com
SKU: 828758595
Availability: InStock
Rating: 4.7 (96 reviews)

Price:	US $ 0.2-0.35/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SC-OM3
Any Length Is Ok:	Boots Colors Can Be Customized
Cable Diameter Can Be Customized:	Cable Jacket PVC or LSZH Can Be Chose
Application:	Sensor
Type:	Multi-mode Fiber
Connection Structure:	SC
Certification:	CCC
Brand:	Tti

Product Description

Multimode OM3 SC/UPC Fiber Optic Pigtail

Fiber patch cord Complies with IEC, Telcordia GR-326-CORE standard
Low insertion loss and high return loss
PC/UPC/APC polishing
Diameter:0.9, 2.0, and 3.0mm
Fiber jumper of the Single or multi mode is available
Simplex or duplex is available
PVC or LSZH cable is available
Excellent changeability and repeatability
Tensile strength:10N
Fiber patch cord operating temperature range:-40 to 80°C
Storage temperature range:-40 to 80°C
Color of fiber optic cable:Yellow (SM), Orange (MM), and Aqua (OM3)
They have some feathers

-Ceramic Ferrule;
- High return loss;
- Low insertion loss;
-Good repeat-ability and and ex-changeability;
- Excellent Polished and 100% tested;
-Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.

We often use them

-Local Area Network (LAN)
-Data communication network
-Telecommunication optical transmission network
-Optical access network(OAN)
-Active device termination
-Fiber optics data transmission(FODT)
-Test Equipment
-CATV

ter	Unit	FC, SC, LC				ST, MU			MT-RJ, MPO
		SM			MM	SM		MM	SM
		PC	UPC	APC	PC	PC	UPC	PC	PC
Insertion loss(typical)	dB	≤0.3	≤0.2	≤0.3	≤0.2	≤0.3	≤0.3	≤0.2	≤0.3
Return loss	dB	≥45	≥50	≥60	≥30	≥45	≥50	≥30	≥45
Operating wavelength	nm	1310, 1510				1310, 1510			1310, 1510
Exchangeability	dB	≤0.2				≤0.2			≤0.2
Vibration	dB	≤0.2				≤0.2			≤0.2
Operating temperature	ºC	-40~75				-40~75			-40~75
Storage temperature	ºC	-45~85				-45~85			-45~85
Cable diameter	mm	φ3.0, φ2.0, φ0.9				φ3.0, φ2.0, φ0.9			φ3.0, φ2.0, φ0.9

Shenzhen TRT Fiber Tech. Co., Ltd is specialized in R&D, manufacturing and marketing of fiber optic such as fiber optic cable, fiber optic patch cord/jumper, fiber pigtail, fiber connector, fiber adapter, fiber attenuator, fiber patch panel, ODF, fiber splice closure and other related fiber products.

With a powerful R&D team, TRT Fiber is able to manufacture products according to customer's specifications and requests, even with customized raw materials. We not only offer OEM service, but also help many partners from all over the world to win in the market with professional technical support, excellent product solution, competitive prices, fast delivery and good service. We ensure every piece of our fiber optic products is with excellent performance and appearance.

TRT has been putting a lot of investments to keep pace with fiber optic industry standard. With high quality raw materials, advanced manufacturing equipments and highly skilled workers, we ensure every piece of our fiber optic products is with excellent performance and appearance.

Welcome to be TRT business partners, we are sure to bring you more profits. Thank you.
