Hot Searches: variable frequency inverter GPS Tracker

Myanmar Electric Wire and Cable/Cable for Myanmar/Cambodia Electric Wire and Cable

Name: Myanmar Electric Wire and Cable/Cable for Myanmar/Cambodia Electric Wire and Cable
Brand: all-electronics-online.com
SKU: 691267291
Availability: InStock
Rating: 4.8 (96 reviews)

Price:	US $ 1/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BV, VV, YJV.
Product Name:	Myanmar Electric Wire and Cable/Cable for Myanmar/
Number Of Cores:	Single/2/3/4/5/6/7/8/10/16 Core...
Rated Voltage:	0.6/1kv,1.8/3kv,3.6/6kv,6/6(10)Kv,8.7/10(15)Kv,12/
Cross Section Area/Measure:	3.5/4/6/10/16/25/35/50/70/95/120/150/185/240/300/4
Standard:	IEC 60502-1, BS 7870-6, BS 6622, BS 7835, GB 5023-
Conductor:	Stranded/Solid/Flexible Copper/Aluminum Conductor
Insulation:	XLPE/PVC/PE/Pur
Aplication:	Electric, House Wire, Building Wire...
Shield:	Copper Wire Screen(Cws), Aluminium Wire Screen(Aws
Armoured:	Steel Tape Armoured (Sta) or Steel Wire Armoured (
Type:	Insulated
Conductor Type:	Stranded
Application:	Electric, Power...
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	VDE
Brand:	Chang Qing Teng

Product Description

myanmar electric wire and cable/cable for myanmar/cambodia electric wire and cable

Product Description

myanmar electric wire and cable/cable for myanmar/cambodia electric wire and cable

Copper Wire Conductor: Copper/Aluminum

Insulation: PVC

Apply voltage: 300/500V 450/750V

Ambient Temperature: Above 0°C

Operation temperature: For PVC insulated wire, Operating temperature should not exceed 70°C except for Type 08.

Type 08 will allow 105°C.

The product is fit for ac rated voltage 450/750 and below of domestic electrical appliances of smaller size motorcade

tools of instruments of various meters and motorized lighting installations.

This product is suitable to be used in household appliances ,electric tools and lighting in home , office and similar

indoor place where request flexible wire.

4. Wire Model

Type	Designation	Core No.	Sectional area (mm²)	Rated Voltaged (V)
60227IEC01 BV	General purpose single core hard conductor wire without sheath	1	1.5~400	450/750
BLV	Al conductor PVC insulated wire	1	2.5~400	450/750
BVR	Cu conductor PVC insulated soft cable	1	2.5~70	450/750
BVV	Light type PVC sheath wire	2~5	1.5~35	300/500
BVV	Cu conductor PVC and sheath circular cable	1	0.75~10	300/500
BLVV	Al conductor PVC and sheath circular cable	1	2.5~10	300/500

Type BVR 450/750V copper conductor PVC insulated flexible wire

Nominal Cross- Section area mm²	Calculation Outer Diameter mm	Max.d.c,resistance at 20°C(Copper-cored) Ω/km	Mini.insulation Resistance at 70°C (Copper-cored) MΩ.km	Product approximate weight kg/km
Nominal Cross- Section area mm²	Calculation Outer Diameter mm	Max.d.c,resistance at 20°C(Copper-cored) Ω/km	Mini.insulation Resistance at 70°C (Copper-cored) MΩ.km	Copper-cored	Aluminum-cored
1x1.5	2.7	12.2	0.011	19.5
1x1.5	2.9	12.1	0.010	19.5
1x2.5	3.3	7.41	0.010	30.8	15.4
1x2.5	3.6	7.41	0.010	31.5
1x4	3.8	4.61	0.0085	45.6	21.0
1x4	4.1	4.61	0.0077	45.6
1x6	4.3	3.08	0.0070	65.3	28.2
1x6	4.7	3.08	0.0065	65.3
1x10	6.0	1.83	0.0065	111	49.0
1x16	7.1	1.15	0.000	169	69
1x25	8.8	0.727	0.000	265	108
1x35	9.9	0.524	0.0040	359	140
1x50	11.1	0.387	0.0045	485	190
1x70	13.5	0.268	0.0035	685	258
1x95	15.8	0.193	0.0035	946	354
1x120	17.4	0.153	0.0032	1181	433
1x150	19.4	0.124	0.0032	1453	534
1x185	21.6	0.0991	0.0032	1821	668
1x240	24.6	0.0754	0.0032	2383	869
1x300	27.5	0.0601	0.0030	2983	1082
1x400	30.8	0.0470	0.0028	3800	1369

Certifications

Certifications: ISO9001/14000, CE, CCC, IEC, BS, EN, VDE

Contact:

1) About Luxing Cable Factory:

-Shandong New Luxing Cable Co., Ltd established in the year of 1999.

-The headquarter is located in Jinan City, the capital of Shandong province, China.

-Registered capital of USD16.5 million, Legal representative Wang Xiuzhen.

-Luxing Cable Factory is located in Linyi Economic Development ZoneCovering an area of more than 60 acres.

-Shandong New Luxing Cable Co., Ltd has more than 150 employees, which college degree more than 50 people.

2)Why Choose Luxing Cable Factory?

-Luxing cable, the designated supplier of China's national grid construction.

-We provid high-quality cables for our clients for more than 18 years.

-The professional, safe and reliable of Luxing factory gained great trust and praise from our customers.

-Serve you any time.

3)The Product of Luxing Cable Factory

-300/500V 450/750V electrical wire

-600/1000V PVC insulated cable

-600/1000V XLPE insulated cable

-1.8/3KV to 26/35KV power cable

-Armored underground cable

-Control cable and instrumentation cables

-ABC cable

-AAC conductor

-AAAC conductor

-ACSR conductor

-OPGW

-Rubber cable

4)Product application

-Used for open air installation, for direct burrial underground, in water, in cable ducts, power stations, for industry and distribution boards and so on.

-Power transmission and distribution project bids we can work, cable retail and wholesale, regional agent we can cooperate.

5)Production Market

-Supply power cables & electrical wire to

South America(Brazil...),

East Asia(Korea...),

Africa(Uganda, South Africa, Zimbabwe...),

Southeast Asia(Myanmar, Thailand, Indonesia, Philippines, Malaysia, Cambodia...),

Europe(Czech Republic...) to global market.

-Had fixed partnership with SGCC&STATE GRID CORPORATION OF China (China largest power enterprise) and many other our country State-owned big enterprise.

6)Our service

-We guarantee that we will comply with the requirements of warranty period specified in the contract, that the Goods supplied under the purchase order For Procurement of self-carrying distribution network's cable and wire.

-We will be manufactured under this specification and that the Goods will be new, unused, of the most recent or current models. Once we are selected, we will supply the Goods strictly according to the requirements of the Contract.

-The warranty shall remain valid for twelve (12) months after the Goods, or any portion thereof as the case maybe, have been delivered to and accepted at the final destination indicated in the SCC, or for eighteen (18) months after the date of shipment from the port or place of loading in the country of origin, whichever period concludes earlier.

-During the warranty period purchaser may proclaim directly to the manufacturer in the written form or by the agent if there is any problem in Goods quality. The manufacturer will do the repair or replacement in reasonable time, and will bear all the expenses relating to this.
