Negative S Type Thermocouple Compensating Wire Sc Fiberglass Jacket

Name: Negative S Type Thermocouple Compensating Wire Sc Fiberglass Jacket
Brand: all-electronics-online.com
SKU: 804272515
Availability: InStock
Rating: 4.4 (126 reviews)

Price:	US $ 0.59-1.5/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	S-HPF-1115
Type:	Insulated
Conductor Type:	Stranded
Insulation Material:	Fiberglass
Certification:	ANSI
Application:	Thermocouple Wires
Conductor Material:	Copper/Nicu
Sheath Material:	Fiberglass
Range Of Application:	Machinery,Thermocouple,Electricity
Brand:	Ohmalloy

Product Description

Negative S Type Thermocouple Compensating Wire SC Fiberglass Jacket

SNC (RNC) is regarded as negative leg for extension grade type S,R thermocouple cable.

1. Chemical Composition

Material	Chemical composition (%)
Material	Ni	Cr	Cu	Mn	Si
RNC(SNC)	0.6		Bal

2. Physical properties and Mechnical properties

Material

Density(g/cm³)

Melting point(ºC)

Tensile Strength(Mpa)

Volume resistivity(μΩ.cm)

Elongation rate (%)

RNC(SNC)

8.9

1400

>390

2.8(20ºC)

>25

3. EMF Value range at different temperature

Material	EMF value Vs Pt(μV)
Material	100ºC	200ºC	300ºC	400ºC	500ºC	600ºC
RNC(SNC)	-108~-148	-376~-1416

EMF value Vs Pt(μV)
700ºC	800ºC	900ºC	1000ºC	1100ºC

Thermocouple grade of conductor material

Grade	K	E	T	N	J	R/S
Positive leg	Chromel/KP	Chromel/EP	Copper/TP	NiCrSi/NP	Fe/JP	Copper/SPC
Negative leg	Alumel/KN	Constantan/EN	Constantan/TN	NiSiMg/NN	Constantan/JN	CuNi/SNC

Normal available condutor size

Solid type	0.2mm	0.3mm	0.5mm	0.8mm	1.0mm	1.13mm	1.29mm	1.37mm
Stranded type	0.2mm*7	0.3mm*7	0.43mm*7	0.52mm*7	0.67mm*7

Note: We also can make the speical size as per client's requirement. SWG/AWG also is available

Product &Package

Ohmalloy Material Co., Ltd is a high-tech enterprise which specialized in making all kinds of alloy such as high resistance alloy, low-resistance copper nickel alloy, precision alloy, FeCrAl alloy and thermocouple Alloy.

Ohmalloy Material Co., Ltd have a full production line from melting, surface cleaning, rolling and slitting, full set of testing machine and can meet all kinds of technical requirement from customer. Our product is widely used in heating equipment, big steel mill, mineral, electrical equipment, food machinery, auto industry, aerospace industry. Our product not only is popular in domestic market, but also been exported to all over the world.

Our company aims to be the best-quality alloy producer in the world. We insist on developing the more advanced alloy strip technology, to serve all the customer, improve people's living level, make a more green earth in the future.

Our company supplies different kinds of products. With high quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
