No Silkscreen Multilayer PCB Board Red Soldermask with OSP Surface
| Price: |
US $ 0.63/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-232-V2.32 |
| Outer Copper Foil: |
1oz |
| Board Thickness: |
1.85-1.92mm |
| Surface Treament: |
OSP |
| Solder Mask: |
Red, Psr-2000gt 600d |
| Legend: |
White, Ijr-4000 MW300 |
| Min Line Width (Mil): |
5.7 |
| Min Line Spacing (Mil): |
5 |
| Electrical Test: |
100% PCB Passed |
| Warp-Twist: |
0.19% |
| Solderability Test: |
245ºC 5s 1 Cycle |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Warpage less than 0.19% Prototype PCB FR-4 8 Layerwith Red Solder Mask and OSP in Car
Amplifier
Commodity Introduction
This is a type of FR-4 PCB for the application of . It's an 8 layer board at 1.85-1.92mm thick. The
base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012
Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.
Parameters & Data Sheet| Item | Requirement | Result |
| Laminate | Type | FR-4 | FR-4 |
| Supplier | ITEQ | ITEQ |
| Board thickness | 2+/-10%mm | 1.85-1.92mm |
| Outer copper foil | >=35 um | 46.78um |
| Inner copper foil | 1/1 OZ | 1/1 OZ |
| Warp-twist | <= 0.75% | 0.19% |
| Legend | Type | IJR-4000 MW300 | IJR-4000 MW300 |
| Color | White | White |
| Location | CS & SS | CS & SS |
| Marking | Co.logo | YES | OK |
| UL.logo | YES | OK |
| Date code | WWYY | WWYY |
| Marking form | NA | OK |
| Location | CS | CS |
| Min line width (mil) | 5.9 | 5.7 |
| Min line spacing (mil) | 4.8 | 5 |
| Min ring width (mil) | NA | NA |
| Solder Mask | Type | PSR-2000GT 600D | PSR-2000GT 600D |
| Color | Red | Red |
| Thickness | >=10 um | 13 um |
| Pencil Test | 6H OR ABOVE | OK |
| SOLVENT TEST | NO ATTACK | OK |
| TAPE TEST | NO PEEL OFF | OK |
| Surface treament | OSP | OK |
| Special Treament | Silk screen | / | / |
| Location | / | / |
| Forming | V-cut | OK |
| Normal Testing | Electrical test | 100% PCB passed | OK |
| Visual inspection | IPC-A-600H&IPC-6012C | OK |
| Solderability Test | 245ºC 5S 1 Cycle | OK |
Finished dimension (unit: mm): including v-cut| No | Required Dimension (tolerance) | Actual Dimension |
| 1 | 290.00 | 289.00 | 289.89 | 290.02 | 289.99 |
| 2 | 150.00 | 150.06 | 150.06 | 150.05 | 149.94 |
Hole size and slot dimension(unit: mm, PTH tolerance +/-0.076, NPTH +/-0.05mm)| No | Required | PTH | Actual Dimension |
| 1 | 0.800 | Y | 0.800 | 0.775 | 0.825 | 0.800 |
| 2 | 0.900 | Y | 0.900 | 0.875 | 0.925 | 0.900 |
| 3 | 0.950 | Y | 0.950 | 0.925 | 0.975 | 0.950 |
| 4 | 1.000 | Y | 1.000 | 0.975 | 1.025 | 1.000 |
| 5 | 1.100 | Y | 1.100 | 1.075 | 1.125 | 1.100 |
| 6 | 1.500 | Y | 1.500 | 1.475 | 1.525 | 1.500 |
| 7 | 1.550 | Y | 1.550 | 1.525 | 1.575 | 1.550 |
| 8 | 1.600 | Y | 1.600 | 1.575 | 1.652 | 1.600 |
| 9 | 1.700 | Y | 1.700 | 1.675 | 1.725 | 1.700 |
| 10 | 2.500 | Y | 2.500 | 2.475 | 2.525 | 2.500 |
| 11 | 3.000 | Y | 3.000 | 2.975 | 3.025 | 3.000 |
| 12 | 3.200 | Y | 3.200 | 3.175 | 3.225 | 3.200 |
| 13 | 3.250 | Y | 3.250 | 3.225 | 3.275 | 3.250 |
| 14 | 3.500 | Y | 3.500 | 3.475. | 3.525 | 3.500 |
| 15 | 3.250 | N | 3.250 | 3.225 | 3.275 | 3.250 |
Learn PCB and Buy PCB
The role of Printed circuit board (PCB)
Printed circuit board (short for PCB) is an important electronic part. It is the supporting body of
electronic component and the electrical connection supporter of electronic component. Since it's
made by electronic printing, it's called printed circuit board.
After PCBs are applied in electronic equipment, since it's consistency of the same board, it
confidently avoids the error of manual wiring. PCB can achieve the automatic pick and place
or surface mounting, automatic soldering, automatic inspection. It guarantees the quality of
electronic equipment. The labor productivity is improved, the cost is reduced and the maintenance
is convenient.
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
