Oil Flow Relay for Oil Immersed Transformer
| Price: |
US $ 100-3000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Product Description
Applicationp
The relay is applicable to protection and monitoring of operating conditions of a transformer oil pump used for strong oil air cooler or strong oli water cooler. It monitor if the oil pump reverses, if the valve opens and if oil flow is normal.
Operating Conditions
The relay's ooperating conditions are as follows:
1 Ambient temperature: -30ºC~45ºC
2 Relative humidity is not more than 90% when air temperature is +25ºC or +-5ºC.
3 The oil temperature is not more than 90ºC.
4 The transformer oil in the cooler should be clean without any foreign matters such as thrum and welding slag.
5 There is no strenuous vibration or bump about around.
Our goods is a major protective device to prevent any internal fault in oil transformer and oil filled on-load tap changer.
Gas relay is a major protective device to prevent any internal fault in oil filled transformer and oil filled on-load tap changer. Gas relay is mounted at the middle of the connection pipe between the transformer and the oil conservator. When internal fault in transformer and on-load tap changer results in oil decomposition to generate gas or sudden oil surge, the contact of the gas relay will operate to connect the designated control circuit, send a signal or automatically disable the trasformer.
Packaging & Delivery
Packaging Details:
Each in brown box
Delivery Detail:
1weeks
Application
The relay is applicable to protection and monitoring of operating conditions of a transformer oil pump used for strong oil air cooler or strong oli water cooler. It monitor if the oil pump reverses, if the valve opens and if oil flow is normal.
Operating Conditions
The relay's ooperating conditions are as follows:
1 Ambient temperature: -30ºC~45ºC
2 Relative humidity is not more than 90% when air temperature is +25ºC or +-5ºC.
3 The oil temperature is not more than 90ºC.
4 The transformer oil in the cooler should be clean without any foreign matters such as thrum and welding slag.
5 There is no strenuous vibration or bump about around.
Operating Principle
An oil flow passes through the adapting pipe after turning on the oil pump,the movable plate will be impelled when the oil flow reaches certain value,and the magnet that has a common axis with the movable plate will be in company with rotation and bring the magnet that is in the indicating part after an interval of thin wall by magnetic force.When the movable plate is impelled to the position at 85 degrees,the magnet in the indicating part also rotates at 85 degresss so that the normally closed contact in the electric part is opened and the normally open contact is closed,giving a normal working signal.The movable plate will return by the aid of spring force and bring the indicating part to return so that the normally open contact in the electric part is opened and the normally clsed contact is closed,giving a trouble singal if the oil flow is reduced to acertain degree.The cooler 's oil pump can be monitored to join the relay's contact outlet into the control box circuit.
Packaging & Shipping
Packaging details:each in foam box
Delivery detail:20 Days
Ningbo Ville Electric Co., Ltd. One of wholly owned subsidiaries of VILLE INDUSTRY, It was invested by VILLE INDUSTRY, It is a well-know listed company in China specialized in R&D of electric power technology, equipment manufacturing and engineering services specialized in research, development, production of transformer and high voltage & low voltage electrical power equipment
Our Transmission and distribution companies can provide with whole solution for transformer substation and switch substation trunkey project!
The rated voltage from 11kV up to 132kV.
It locates in Hi-technical enterprise R & D center zone of Ningbo, Zhejiang province, which is one of the well-know coastal city in China. Its professional engaged in power substation, power plant project and electrical power complete equipments.
Working field: Manufacturing, engineering, designing, executing and commissioning for HV and LV electrical products. Turnkey substation from 11KV to 132KV.
Our transformer factory main working is visiting end user's site do measure and reseach before designe, and providing economic transformer solution for customer. Engineering, manufacturing, executing, commissioning and repairing for different kind of transformer (04kv -500kv ).
The products are mainly used in Steel plant; Power - Fossil fuel plant, Nuclear power plant, Railway, Subway and Airport. Wind power generation; Hydroelectric plant engineering; International power generation plant; Power substation transmission and distribution; Residential housing estate power distribution system and so on.
Transformer factory Product includes:
Three phase double (three)- winding power transformer, generator power transformer, auto power transformer, rectifier transformer for each industry, furnace transformer, movable transformer, traction transformer and reactor, power plant auxiliary and standby transformers, transformers for substations of backbone and distribution networks. Transformer for metallurgical companies etc.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide transformer supplier"
Supply the guide drawings and installation manuals information directions on the method of handling, storage, mounting and erection of transformers.
Power equipment application:
Power-fossil fuel plant, Steel plant, Infrastructure- railway, international generation, substation, hydropower station, wind power substation, transmission and distribution.
We has excellent experience and good capacity in complete projects equipments in Generation, Substation, Transmission and Distribution from 400V-330kv, especially in Power plant, Substation construction and Transmission line, including of design, complete equipment, installation, Commissioningand after-sales service, and also design the complete Electrical Solutions according to customer's demand. We are mainly services to International State Power Board, Power Construction Contractor, Power Project Contractor, Factories and the Electric Power Project in the world.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide electrical equipment supplier
