OLED Displaylevel Switch Mpm5589

Name: OLED Displaylevel Switch Mpm5589
Brand: all-electronics-online.com
SKU: 733796805
Availability: InStock
Rating: 5 (57 reviews)

Price:	US $ 1-50/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	MPM5589
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Accuracy:	<2%Fs
Swich Display:	2 Red LED
Screen Diaplay:	OLED
Hysteresis:	+-0.1%Fs
Power Supply:	12V~30VDC
Protection:	IP65
Storage Temp:	-40~80c
Operation Temp:	-20~70c
Media Temperature:	0~60c
Housing:	Stainless Steel

Product Description

OLED Display Level Switch MPM5589

Features:
1. OLED display;
2. Display rotate 180o;
3. Modbus communication;
4. Body rotate 330o

Applications:
1. Water supply;
2. Water treatment;
3. Metallurgy;
4. Sewage;

Specifications:

Range: 1mH2O,3mH2O,5mH2O
Range Drift: 25%FS~100%FS
Accuracy: <2%FS
Hysteresis: ±0.1%FS
Power supply: 12V~30VDC
Thermal error: ±0.02%FS/ºC(Zero/FS)
Long Time Stability:±0.3%FS/
Media: water, synthetic oil and mineral based hydraulic oil

Outputs:
1 switch: 1×PNP
2 switches: 2×PNP
1 switch + voltage output: 1×PNP + 0V~ 5VDC/10VDC
2 switches + voltage output: 2×PNP + 0V~5VDC/10VDC
1 switch + current output: 1×PNP + 0mA/4mA~20mADC
2 switches + current output: 2×PNP + 0mA/4mA~20mADC
Switch current: 1.2A(Max.)
Switch reaction: <10ms
Switch time delay: 0.00s~99.99s
Switch action pattern: Hys. Mode / Win. Mode

Note: MS701 Communication adaptor shall be used to realize Modbus Communication function.

Screen display: Blue 128×64 OLED Switch display: 2 red LED Display units: cmminch Key: 3 silicone rubber keys, please operate according to instructions on the screen. Temperature display: referenced environment temperature Peak display: Level peak in process	Working Temperature: -20ºC~70ºC Media temperature: 0ºC~60ºC Storage Temperature: -40ºC~80ºC EMC: GB/T 17626.2/3/4-2006 Shock:≤10g/10Hz...500Hz(IEC 60068-2-6-2007) Impact: ≤50g/11ms(IEC 60068-2-27-2008) Protection: IP65 (housing), IP68 (probe)
Probe: SS, NBR Housing: SS Display board: PMMA Diaphragm: SS 316L O-ring: Viton Rubber Electric connection:M12×1 round plug Gross weight: 570g, including 2m breath cable

Order guide:

MPM5589	Intelligent Level Switch
	Code	Level Measurement Range
	X1	[0~1]mH2O
	X2	[0~3]mH2O
	X3	[0~5]mH2O
		Code	Cable Length (L is cable length, m in unit)
		L	At user's request
			Code	Output
			1K	1xPNP
			2K	2xPNP
			1KV	1xPNP+0V~5/10VDC
			2KV	2xPNP+0V~5/10VDC
			1KA	1xPNP+0/4mA~20mADC
			2KA	2xPNP+0/4mA~20mADC
				Code	Thread/flange
				C17	R3/4 male
				F3	DN10 Flange
					Code	Others
					R5	5-pin M12X1 male plug
					R8	8-pin M12X1 male plug for Modbus communication
MPM5589	X2	5	1KA	C17	R5	←the whole spec.

Micro Sensor Co., Ltd, the leading manufacturer of piezo-resistive pressure sensors and transmitters in China, was founded by Sino-US joint venture in 1993. We are providing pressure sensing & measuring solutions to customers all over the world.

With Digital Wide-Temperature Compensation, Non-linearity Correction and Data-Collection by Bus Operation, we supply users OEM pressure sensors, pressure transmitters, level transmitters, measuring and controlling instruments, which have high quality and reliable performance in the local on-site environment.

Based on more than 20 years production experiences, Micro Sensor now have manufacturing capacity of 1.2 million pieces pressure sensors and 400 thousand pieces transmitters in one year. And we are also capable to satisfy the customized specification and designs according to clients' Specified requirements.

Quality is the life of company. Micro Sensor executes I S O 9 0 0 1 International Management System strictly to make sure every procedure qualified in our production. Furthermore, the main products for pressure sensors and transmitters, are also certificated by C E, R o H S, C B, U L and A T E X respectively for different global markets.

Micro Sensor now does business with customers more than 70 countries. More and more global friends know Micro Sensor and make win-win cooperation with us. Wherever you are, whenever you are, find Micro Sensor for any pressure sensing & measuring question. We are looking forward to supporting you with our best services!
