Om3 Multi Mode ST/PC Fiber Optic Patch Cord

Name: Om3 Multi Mode ST/PC Fiber Optic Patch Cord
Brand: all-electronics-online.com
SKU: 749363915
Availability: InStock
Rating: 5 (125 reviews)

Price:	US $ 1.0-1.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	ST/PC Patch Cord
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Connector Type:	ST/PC
Length:	3m (Optional)
Od:	3.0mm
Application:	Communication
Type:	Multi-mode Fiber
Certification:	ISO9001
Brand:	Daytai
Sheath Material:	PVC or Lszh
Connection Structure:	ST/PC to ST/PC

Product Description

Description
Optical Fiber Patch Cord, ST/PC to ST/PC connector, MM, OM3 (150) , single core, OD: 3.0MM,PVC or LSZH Jacket is optional,Length:3M (The length of other requirements canbe provide).

Feature
Insertion Loss: APC<0.3dB .
                           PC<0.2Db.
                           UPC<0.15dB.
Return Loss: SM: PC>45dB.
                               UPC>50dB.
                               APC>60dB.
                          MM: >35dB.
Repeatability: ≤ 0.1dB.
Exchange: ≤0.2dB.
Push-pull Performance:≥1000 Cycle.
Operation Temperature: -40~+80ºC.

Applications:
Long Distance OpticalCommunication.
Optical Testing System.
LAN and MAN.
CATV System.
Digital Communication System.

ReliabilityText Condition:

Item		Text Condition	Text Value
Optical	Insertion Loss	1.3um LED Laser	≤0.2dB
Optical	Return Loss	1.3um LED Laser	≥50dB
Mechanized	Exchange	Interchangeable Random	<0.2dB
	Vibration	5~2000Hz,1.5mm Amplitude	<0.1dB
	Push-pull	>1000 Cycle	<0.1dB
Environments	High Temperature Storage	+85ºC For 100h	<0.2dB
	Low Temperature Storage	-40ºC For 100h	<0.2dB
	Temperature Storage	-40ºC~+85ºC, 50 Cycles	<0.2dB
	Relative Humility	+25ºC~+65ºC, 93%R.H, For 100h	<0.2dB
