RG6 Coaxial Cable TV Patch Cord TV Patch Cable
| Price: |
US $ 1-3/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
RG6/TV Patch Cord |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Connector Type: |
F Male to TV Jack IEC Male or IEC Female |
| Length: |
1m,1.5m,3m,5m Is Optional |
| Color: |
Blue, Black, White (Optional) |
| Conductor Number: |
2/4/6/8 |
| AWG: |
24AWG/26AWG/28AWG |
| Jacket Material: |
PVC/PE |
| Conductor: |
Bare Copper |
| Certification: |
RoHS |
| Application: |
Coaxial Cable |
| Conductor Material: |
Copper |
| Type: |
TV Patch Cord |
| Brand: |
Daytai |
| Cover Material: |
PVC/PE |
Product Description
1. Specifications of RG6 Coaxial Cable TV Patch Cord TV Patch Cable
* RG6/TV Patch Cord
* F Male to TV Jack IEC Male or IEC Female Connector
* Length:1M,1.5M,3M,5M is optional.
2. Application:
* Used in cable TV operations,Computer net-working etc.
3. Construction:
* Solid annealed bare copper conductor polythelene insulated shielded with polyester backed aluminium tape and additional shielding with fine aluminium braid protected with polyester tape wrapping and sheathed with PVC.
4. Specifications:
* 1.63mm Solid Bare Copper +7.11mm Foamed PE +Bonded AL Tape+60% AL Braid+ 10.00mm PVC
* Customers' specifications are welcomed.
5. Note:
* Center conductor: Tinned Copper, Bare Copper, and Copper Clad Steel available;
* Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, And double non-bonded Al-foil are available;
* Braiding wire: AL, Bare Copper and Tinned Copper available;
* Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
* Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available;
* Braiding coverage: Between 30- 97% available;
* PVC jacket of Flame retardant, UV, or UL available.
