Optical Fiber Cable 2-144c GYFTY Outdoor with Stranded Loose Tubes
| Price: |
US $ 10/Meter |
| Trade Terms: |
FOB |
| Min Order: |
2000/Meter |
| Pay Type: |
L/C,T/T |
| Prod Model: |
GYFTY |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outer Sheath Color: |
Black |
| Central Stranding Member: |
Steel Wire or FRP |
| Installation Style: |
Aerial |
| Waterblocking Material: |
Water Blocking Tape or Filling Compound |
| Brand Name Of Fiber: |
Corning ,Yofc,Draka,Fujikura or as Your Requiermt |
| Second Armour Material: |
Corrugated Aluminium Tape |
| Application: |
Communication |
| Type: |
Single-mode Fiber |
| Certification: |
ISO9001 |
Product Description
Optical Fiber Cable 2-144C GYFTY Outdoor with Stranded Loose Tubes Product Description
Manufacturer Supply Hot Sales Optical Fiber Cable GYFTY 1km Price
Product Description
| Product name | GYFTY |
| Introduction | The fibres,250μm,are positioned in a loose tube made of a high modulus plastic.The tubes are filled with a water-resistant filling compound.A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular core. After the cable core is filled with the filling compound to protect it from water ingress,the cable is completed with a PE sheath . |
| Characteristics | Good mechanical and temperature performance |
| High strength loose tube that is hydrolysis resistant |
| Special tube filling compound ensure a critical protection of fiber |
| Crush resistance and flexibility |
| The following measures are taken to ensure the cable watertight: |
| Single Fiber Reinforced Plastic as the central strength member |
| Loose tube filling compound |
| 100% cable core filling |
| Application | Duct or Aerial |
| Standards | Complies with standard YD/T 901-2009 as well as IEC 60794-1. |
Packaging & Shipping
| Packaging | Wooden drum, 3000m to 5000m/drum or as you required |
| Shipping methods. | By sea or by air |
Sheath mark
applied at 1-meter intervals | a. Supplier: Changguang or as customer required |
| b. Standard Code(Product Type, Fiber Type, Fiber Count) |
| c. Year of manufacture: xxx |
| d. Length marking in meters |
Our Services
♦ We are the one of biggest manufacture of fiber optic cable in China and has more than 10 years manufacturing and selling experience.
♦ We accept OEM. The cable size and material are customized.Ur own logo and
own design are welcome. We will produce according to ur requirment and description;
♦ Please send us inquiry for more products info and we will give you feedback in 12 hours.
Company Information
| Company Scale | Covering an area of 170,000 square meter,with product lines for fiber optic cable and cable accessories , total more than 150 professional workers |
| Brands | CHANGGUANG |
| Production capabilities | 5000KM per week |
| Product series | Indoor and outdoor fiber optic cable, ADSS fiber cable and OPGW cable, fiber optic patch cord, pigtail and other cable accessories |
| Quality control | We have strict test on each production line |
| Trade shows attended | 2 times canton fair and one oversea fair at least every year |
| Main export markets | Central/South America, Mid East/Africa, Eastern Europe, North America, Asia, Western Europe, Australasia ,etc |
FAQ
| Payment terms | T/T,L/C,ESCROW ,D/A,D/P, Western Union, MoneyGram, Paypal |
| MOQ. | 1km/order |
| Delivery Time | Within 3 to 7 working days, but most depends on your quantity |
| Loading Port | Shanghai or Lianyungang or qingdao China |
| OEM | Yes |
| Place of Origin | Suqian, China |
| Quote Request Information | Fiber Count: 2 to 288 Fibers |
| Fiber type: Single mode: G652D, G655,G657. Multimode: 50/125,62.5/125. OM3 |
| Order Quantity |
DONGGUAN TW-SCIE Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication
Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.
The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.
The main products of our enterprise are:
Optical fiber, optical cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.
All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.
