OSP 1.2mm Thick Multilayer PCB Board Red Solder Mask
| Price: |
US $ 0.62/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-233-V2.33 |
| Outer Copper Foil: |
1 Oz |
| Board Thickness: |
1.2mm |
| Surface Treament: |
OSP |
| Solder Mask: |
Red |
| Legend Color: |
White |
| Min Line Width (Mil): |
5.6 Mil |
| Min Line Spacing (Mil): |
5.7 Mil |
| Electrical Test: |
100% PCB Passed |
| Solderability Test: |
245ºC 5s 1 Cycle |
| Visual Inspection: |
Ipc-a-600h&Ipc-6012c |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
1.2mm Thick Multilayer PCB board 8 Layer 1oz with Red Solder Mask 100% Test Pass for
Shipment OSP PCB in Gps Tracking Device
Commodity Introduction This is a type of FR-4 PCB for the application of Gps Tracking Device. It's an 8 layer board at
1.2mm thick. The base laminate is from ITEQ, Solder mask and silkscreen from KUANG SHUN.
It's fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are
packed separately.
Parameters & Data Sheet| Item | Requirement | Result |
| Laminate | Type | FR-4 TG170 | FR-4 TG170 |
| Supplier | ITEQ | ITEQ |
| Board thickness | 1.2+/-10%mm | 1.18-1.21mm |
| Outer copper foil | >=35 um | 43.37 |
| Inner copper foil | 1/1 OZ | 1/1 OZ |
| Warp-twist | <= 1% | 0.79% |
| Legend | Type | KUANG SHUN | KUANG SHUN |
| Color | White | White |
| Location | CS | CS |
| Marking | Co.logo | YES | OK |
| UL.logo | YES | OK |
| Date code | WWYY | WWYY |
| Marking form | NA | OK |
| Location | CS | CS |
| Min line width (mil) | 5.4 | 5.6 |
| Min line spacing (mil) | 5.9 | 5.7 |
| Min ring width (mil) | NA | NA |
| Solder Mask | Type | KUANG SHUN | KUANG SHUN |
| Color | Red | Red |
| Thickness | >=10 um | 14 um |
| Pencil Test | 6H OR ABOVE | OK |
| SOLVENT TEST | NO ATTACK | OK |
| TAPE TEST | NO PEEL OFF | OK |
| Surface Treament | OSP | OK |
| Special Treament | Silk screen | / | / |
| Location | / | / |
| Forming | V-cut | OK |
| Normal Testing | Electrical test | 100% PCB passed | OK |
| Visual inspection | IPC-A-600H&IPC-6012C | OK |
| Solderability Test | 245ºC 5S 1 Cycle | OK |
Finished dimension (unit: mm): including v-cut| No | Required Dimension (tolerance) | Actual Dimension |
| 1 | 136.19 | 136.31 | 136.26 | 136.27 | 136.30 |
| 2 | 146.20 | 146.20 | 146.28 | 146.17 | 146.30 |
