Outstanding Reliability Ycm1moulded Case Circuit Breaker /MCCB

Product Description

Outstanding reliability YCM1 moulded case circuit breaker /mccb

1.General

1.1 Electric ratings:AC 690V,50/60Hz,10~800A;

1.2 Mounting mode: vertical and horizontal;

1.3 Standard:IEC/EN60947-2

2.Type designation

YCM1- /

 2.1 YC:company code

 2.2 M:MCCB

 2.3 1:design sequencenumber

 2.4 :frame size

 2.5 :code of breaking capacity:L/M/H

 2.6 :operation mode

 2.7 :number of poles

 2.8 :release type and accessory code

 2.9 :application

2.10 :type of N-pole for 4-P breaker


3.Operation conditions

3.1 Temperature:

      -5°C~+40°C; the average value within 24h shall not exceed +35°C.For the circuit breaker with thermo-magnetic release,+40°C is set to be the standard temperature for rating.For temperature not between -5°C~+40°C,please contact us for temperature compensation correction:

3.2 Altitude:

      Not exceed 2000m(Please contact with us for reduction coefficient if altitude at the mounted site exceed 2000m)

3.3 Air conditions:

     At mounting site,relative humidity not exceed 50% at the max temperature of +40°C,higher relative humidity is allowable under lower temperature.For example,RH could be 90% at +20°C,special measures should be taken to occurrence of dews.


 4.Specifications

About CNC:

1.China top 500 enterprises.

2.26 years rich experiences in manufacturing electrical products.

3.Sales in over 100 countries.

4.Pass ISO9001,ISO14001,CCC,CE,CB,IEC,ICO certificate and standard.
