| Prod Model: |
AAC conductor |
| Product Name: |
Overhead All Aluminium Stranded AAC Conductor |
| Standard: |
CSA IEC ASTM DIN BS GOST Sas |
| Applicable Voltage: |
Low Voltage, Medium Voltage, High Voltage |
| Type Of Conductor: |
Stranded, Bare |
| Certificate: |
ISO9001, CCC, CQC, Ohsas, TUV, etc. |
| Transportation: |
by Sea or as Your Requirement |
| Supplier's Nature: |
Manufacturer, Exporter |
| Core: |
According to Your Requirement |
| Manufacturer Experience: |
Since 2006 |
| Factory Area: |
200, 081mm2 |
| Type: |
Bare |
| Conductor Type: |
Stranded |
| Application: |
Overhead |
| Conductor Material: |
Aluminum |
| Certification: |
Ohsas |
| Sheath Material: |
Bare |
| Insulation Material: |
No Insulation |
| Range Of Application: |
Overhead LV, Mv, Hv |
| Brand: |
Dayuan |
Product Description
All Aluminium Conductor Overhead Bare Aluminium Stranded Wire AAC Conductor
Product Description
Material Standard:
ASTM-B232 Standard specification for Concentric-Lay-Stranded Aluminum 1350 Conductors
BS215-2 aluminum conductors steel-reinforced -For overhead power transmission
DIN48204 Steel reinforced aluminum stranded conductors
IEC209 Aluminum stranded conductor steel reinforced
Technical characteristics
We could produce most of the standards cables, such as ASTM, BS, CSA, DIN, GB and IEC Standards, etc.
| Code | Size | Section | No. of Strands | Diameter Strands | Weight | Rated Strength | Maximunm Resistance
@20°C |
|
|
| AWG o MCM | in² | mm | mm | kg/km | kg | Ω/km |
| Peachbell | 6 | 13.3 | 7×1.56 | 4.66 | 36.6 | 254 | 2.170 |
| Rose | 4 | 21.15 | 7×1.96 | 5.88 | 58.3 | 399 | 1.364 |
| Iris | 2 | 33.62 | 7×2.47 | 7.42 | 92.7 | 611 | 0.857 |
| Pansy | 1 | 42.41 | 7×2.78 | 8.33 | 117 | 740 | 0.681 |
| Poppy | 1/0 | 53.51 | 7×3.12 | 9.36 | 147.5 | 897 | 0.539 |
| Aster | 2/0 | 67.44 | 7×3.50 | 10.51 | 186 | 1136 | 0.427 |
| Phlox | 3/0 | 85.02 | 7×3.93 | 11.8 | 235 | 1375 | 0.339 |
| Oxlip | 4/0 | 107 | 7×4.42 | 13.25 | 296 | 1738 | 0.268 |
| Daisy | 266.8 | 135 | 7×4.96 | 14.88 | 373 | 2191 | 0.213 |
| Laurel | 266.8 | 135 | 19×3.01 | 15.05 | 373 | 2254 | 0.213 |
| Tulip | 336.4 | 171 | 19×3.38 | 16.9 | 470 | 2786 | 0.169 |
| Canna | 397.5 | 201 | 19×3.68 | 18.38 | 555 | 3219 | 0.143 |
| Cosmos | 477 | 242 | 19×4.02 | 20.12 | 666 | 3803 | 0.119 |
| Syringa | 477 | 242 | 37×2.88 | 20.18 | 666 | 3932 | 0.119 |
| Dahlia | 556.5 | 282 | 19×4.35 | 21.73 | 777 | 4431 | 0.102 |
| Mistletoe | 556.5 | 282 | 37×3.11 | 21.8 | 777 | 4495 | 0.102 |
| Orchid | 636 | 322 | 37×3.33 | 23.31 | 888 | 5154 | 0.089 |
| Violet | 715.5 | 363 | 37×3.53 | 24.73 | 1000 | 5791 | 0.079 |
| Nasturtium | 715.5 | 363 | 61×2.75 | 24.76 | 1000 | 5960 | 0.079 |
| Arbutus | 795 | 403 | 37×3.72 | 26.07 | 1110 | 6303 | 0.071 |
| Lilac | 795 | 403 | 61×2.90 | 26.11 | 1110 | 6501 | 0.071 |
| Anemone | 874.5 | 443 | 37×3.91 | 27.37 | 1222 | 6821 | 0.065 |
| Crocus | 874.5 | 443 | 61×3.04 | 27.36 | 1222 | 7144 | 0.065 |
| Magnolia | 954 | 483 | 37×4.08 | 28.55 | 1333 | 7428 | 0.059 |
Overhead Line AAC AAAC ACSR ACSR Conductor ACSR Cable
ACSR (Aluminum Conductor Steel Reinforced) Cable consisting of a galvanized steel
core, is surrounded by concentric layers of aluminum wire, and grease if necessary.
ACSR cable is widely used in the overhead power distribution system in our country.
We can supply this conductor according to different recognized standards, such as IEC61089, BS215, ASTM B232, CSA C49, DIN48204, JIS C3110, and customers' special
specifications also can be satisfied.
Overhead Line AAC AAAC ACSR ACSR Conductor ACSR Cable Application:
Conductor (AAC and ACSR) have been widely used in power transmission lines with
various voltage, because they have such good characteristics as simple structure,
convenient installation and maintenance, low cost and large transmission capacity.
Overhead Line AAC AAAC ACSR ACSR Conductor ACSR Cable Specifications:
ACSR bare conductor meets or exceeds the following ASTM specifications:
B-230 Aluminum Wire, 1350-H19 for Electrical Purposes
B-231 Aluminum Conductors, Concentric-Lay-Stranded
B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced
(ACSR)
B-341 Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced
(ACSR/AZ)
B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced
(ACSR/AZ)
B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors,
Steel Reinforced (ACSR)
Overhead Line AAC AAAC ACSR ACSR Conductor ACSR Cable Material Standard:
1) The hard aluminum conductor used for AAC and ACSR conforms to the standard GB/T 17048-1997 (equivalent to IEC 60889:1987)
2) The zinc coated steel wire used for ACSR cable confirms to IEC 60888:1987
3) Production can be arranged according to customers' requirement such as material standard etc.
4) We can also produce products according to the Standard of BS215, ASTM B232, and DIN48204
