PCB Board 3.2mm Thick 0.126" It158 Fr-4 Ipc Class 3
| Price: |
US $ 1.2/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-575-V5.75 |
| Board Thickness: |
0.10mm |
| Tg Value Of Board Material: |
60ºC |
| Surface Cu Thickness: |
35 µm |
| Coverlay Colour: |
Yellow |
| Color Of Silkscreen: |
White |
| Peeling Test Of Coverlay: |
No Peelable |
| Surface Finish: |
Immersion Gold |
| RoHS Required: |
Yes |
| Pth Cu Thickness: |
≥20 µm |
| Function: |
100% Pass Electrical Test |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Application of Antenna |
| Insulation Materials: |
Polyimide |
| Brand: |
Bicheng |
Product Description
Company Profile
Bicheng Enterprise Limited which was founded in Shenzhen China in 2003 is a professional
PCB export enterprise. We have established a good relationship of cooperation with well-known
enterprises in the same industry. Our PCB products range from fiberglass PCB, high frequency
PCB to metal core PCB and ceramic PCB's. This is a unique printed circuit board supplier and
export enterprise. She has groups of skilled manufacturing facilities just like the experienced
football players in the football field and every batch of shipment is like a beautiful gift transmitted
to your hands.
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Laminates --- FR-4 Applied on printed circuit boards (PCBs)
FR-4 grade materials are generally used on the circuit board has many types, but most are based
on the so-called four function (Tera-Function) composite material which is composed of woven
fiberglass cloth with an epoxy resin binder that is flame resistant.
FR-4 is the primary insulating backbone upon which the vast majority of rigid printed circuit boards
(PCBs) are produced. A thin layer of copper foil is laminated to one or both sides of an FR-4 glass
epoxy panel. These are commonly referred to as copper clad laminates (CCL).
FR-4 copper-clad sheets are fabricated with circuitry interconnections etched into copper layers to
produce printed circuit boards (PCBs). More sophisticated and complex FR-4 printed circuit boards
(PCBs) are produced in multiple layers, also known as "multilayer circuitry".
Bicheng Flexible Printed Circuit Capability| No. | Specifications | Capabilities |
| 1 | Board Type | Single layer, Doulbe layer,
Multilayer, Rigid-Flex |
| 2 | Base Material | PI, PET |
| 3 | Copper Weight | 0.5oz, 1oz, 2oz |
| 4 | LED Maximum Size | 250 x 5000mm |
| 5 | General Maximum Size | 250 x 2000mm |
| 6 | Board Thickness | 0.03mm-3.0mm |
| 7 | Thickness Tolerance | ±0.03mm |
| 8 | Mininum Drill Hole | 0.05mm |
| 9 | Maximum Drill Hole | 6.5mm |
| 10 | Tolerance of Drill Hole | ±0.025mm |
| 11 | Thickness of Hole Wall | >= 8 um |
| 12 | Minimum Track/Gap
of Single Layer Board | 0.025/0.03mm |
| 13 | Minimum Track/Gap of Double
Layer and Multilayer Board | 0.03/0.040mm |
| 14 | Etching Tolerance | ±0.02mm |
| 15 | Minimum Width of Silk Legend | >= 0.125mm |
| 16 | Minimum Heigh of Silk Legend | >=0.75mm |
| 17 | Distance from Legend to Pad | >=0.15mm |
| 18 | Distance from Opening Solder
Mask of Drill Coverlay to Track | >=0.03mm |
| 19 | Distance from Opening Solder
Mask of Punching Coverlay to Track | >=0.03mm |
| 20 | Thickness of Immersion Nickel | 100-300u" |
| 21 | Thickness of Immersion Gold | 1-3u" |
| 22 | Thicnkess of Immersion Tin | 150-400u" |
| 23 | Minimum Electrical Testing Pad | 0.2mm |
| 24 | Minimum Tolerance of Outline
(Normal Steel Mould Punch) | ±0.1mm |
| 25 | Minimum Tolerance of Outline
(Precision Steel Mould Punch) | ±0.05mm |
| 26 | Mininum Radius of Bevel Angle (Outline) | 0.2mm |
| 27 | Stiffner Material | PI, FR-4, 3M Adhesive, PET, Steel Sheet |
| 28 | RoHs | Yes |
| 29 | Solder Mask Colour | Yellow, White, Black, Green |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
