PCB Board 6 Layer 1 Oz Red Mask OSP Finish
| Price: |
US $ 0.64/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Paypal |
| Prod Model: |
BIC-231-V2.31 |
| Outer Copper Foil: |
1 Oz |
| Board Thickness: |
1.6mm |
| Surface Treament: |
OSP |
| Solder Mask: |
Red,Psr-2000gt 600d |
| Legend: |
White,Ijr-4000 MW300 |
| Min Line Width (Mil): |
7.7 Mil |
| Min Line Spacing (Mil): |
5.7 Mil |
| Electrical Test: |
100% PCB Passed |
| Visual Inspection: |
Ipc-a-600h&Ipc-6012c |
| Solderability Test: |
245ºC 5s 1 Cycle |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Tg170 FR-4 Printed circuit board 6 Laye 1oz for Each Layer with Red Solder Mask PSR-
2000GT 600D OSP finish in Remote Control
Commodity Introduction
This is a type of FR-4 PCB for the application of Remote Control. It's a 6 Layer board at 1.6mm
thick.The base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per
IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.
Parameters & Data Sheet| Item | Requirement | Result |
| Laminate | Type | FR-4 TG170 | FR-4 TG170 |
| Supplier | ITEQ | ITEQ |
| Board thickness | 1.6+/-10%mm | 1.5-1.60mm |
| Outer copper foil | >=35 um | 43.37 um |
| Inner copper foil | 35um | 35um |
| Warp-twist | <= 0.75% | 0.35% |
| Legend | Type | IJR-4000 MW300 | IJR-4000 MW300 |
| Color | White | White |
| Location | CS | CS |
| Marking | Co.logo | As requirement | OK |
| UL.logo | As requirement | OK |
| Date code | As requirement | OK |
| Marking form | As requirement | OK |
| Location | CS | CS |
| Min line width (mil) | 7.9 | 7.7 |
| Min line spacing (mil) | 5.5 | 5.7 |
| Min ring width (mil) | NA | NA |
| Solder Mask | Type | PSR-2000GT 600D | PSR-2000GT 600D |
| Color | Red | Red |
| Thickness | >=10 um | 14um |
| Pencil Test | 6H OR ABOVE | OK |
| SOLVENT TEST | NO ATTACK | OK |
| TAPE TEST | NO PEEL OFF | OK |
| Surface Treament | OSP | OK |
| Special Treament | Silk screen | / | / |
| Location | / | / |
| Forming | V-cut | OK |
| Normal Testing | Electrical test | 100% PCB passed | OK |
| Visual inspection | IPC-A-600H&IPC-6012C | OK |
| Solderability Test | 245ºC 5S 1 Cycle | OK |
Finished dimension (unit: mm): including v-cut| No | Required Dimension (tolerance) | Actual Dimension |
| 1 | 186.00 | 186.07 | 185.10 | 185.95 | 185.93 |
| 2 | 181.00 | 180.95 | 180.90 | 180.93 | 181.10 |
Hole size and slot dimension(unit: mm, PTH tolerance +/-0.076, NPTH +/-0.05mm)| No | Required | PTH | Actual Dimension |
| 1 | 0.900 | Y | 0.900 | 0.875 | 0.925 | 0.900 |
Learn PCB and Buy PCB
The process of multilayer PCB
A) In general, a multilayer board consists of a number of very thin print-and-etch inner layers, but
drilling of holes has not been carried out. Outer layers of the multilayer board remain unetched.
B) Layers from top to bottom are bonded together in close registration by means of thin plies of
prepreg. The bonding is performed under close temperature and pressure control in a lamination
press.
C) After lamination, they are the processed in very much the same way as an ordinary double-
sided PTH boards, i.e. holes are drilled, cleaned and plated. Outer layers are etched to develop
the circuit pattern. Solder masks are applied and solder coating (HAS, ENIG etc) is performed.
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
