PCB Board Aluminum Core 2.0mm Thick 0.079" Plated Milling Cutouts
| Price: |
US $ 1.15/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-572-V5.72 |
| Board Thickness: |
0.15mm |
| Tg Value Of Board Material: |
60ºC |
| Surface Cu Thickness: |
35µm (1oz) |
| Pth Cu Thickness: |
≥20 µm |
| Coverlay Colour: |
Yellow |
| Color Of Silkscreen: |
White |
| Stiffener Thickness: |
0.2mm |
| Surface Finish: |
Immersion Gold |
| RoHS Required: |
Yes |
| Function: |
100% Pass Electrical Test |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Application of Antenna |
| Insulation Materials: |
Polyimide |
Product Description
Company ProfileFounded in Shenzhen China in 2003, Bicheng Enterprise Limited is a professional PCB export
enterprise.
More than 15 years of PCB experiences
Excellent after-sales service
Substrate material: Epoxy glass (FR-4), High frequency, Metal core
Price advantages on circuit boards
Multilayer PCB and Hybrid material of Multilayer PCB
Focus on prototypes, small batches and volume production
TS16949 (2009), ISO14001 (2004), ISO9001 (2008), UL certified
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Design For Manufacture| Serial NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 84 | Special tolerance | Board thickness
of flying probe
test | 0.6-4.0mm |
| 85 | Panel size of
flying probe test | Size≤900X600mm,
Small size can be
compensated through
manufacturing procedure |
| 86 | Panel size of
fixture test method | Size≤460X380mm,
Small size can be
compensated through
manufacturing procedure |
| 87 | Board thickness of
fixture test method | 0.4-6.0mm |
| 88 | Tolerance of
press-fit hole | ±2mil |
| 89 | Tolerance of NPTH | ±2mil |
| 90 | Tolerance of PCB
thickness | 1.0mm≥PCB thickness,
Tolerance ±0.1mm;
1.0mm≤PCB thickness,
Tolerance ±10% |
| 91 | Tolerance of depth
of countersunk hole | ±0.2mm |
| 92 | Depth tolerance of
blind slot | ±0.2mm |
| 93 | Maximum shipment
size | Size≤1200X600mm
(Double side, no test
required) |
| 94 | Size≤1000X600mm
( Multilayer, no test
required) |
| 95 | Minimum shipment
size | 10X10mm |
| 96 | PCB thickness of
HASL | 0.8-3.0mm
(Hole less 0.5mm
should be use via-plug
or mask-tent ) |
| 97 | HASL PCB Size | Size≤600X460mm |
| 98 | PCB thickness | 0.15-7.0mm |
| 99 | Depth of V
groove | 0.8-3.2mm |
| 100 | Distance of
non-continuous
v-groove | ≥7mm |
| 101 | Max. drill diameter | Size≤6.5mm
(Counterbore
or router will be
used for holes more
than 6.5mm, Min.tolerance
±0.1mm ) |
| 102 | Max. countersink
diameter | Size≤6.5mm
Countersink can
be used counterbore
drill or router) |
| 103 | Distance of Bevel | Size≥11mm | Size≥5mm | Size≥5mm |
| 104 | Thickness of
peelable
mask | 0.2-1.5mm ±0.15mm |
The creator of printed circuit board is Austrian engineer Paul Eisler. He invented the printed circuit
as part of a radio set while working in England around 1936. In 1943, The USA began to use the
technology on military radio. In 1948, the USA released the invention for commercial use. Since
the mid-1950s, printed circuits became commonplace in consumer electronics and began to be
widely used.
Before PCB, the interconnection between the electronic components is relying on the wires directly
connected to complete. Nowadays, only in the laboratory test wire exists. Printed circuit board in
the electronics industry has occupied the absolute control status.
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
