PCB Board Double Sided 1.6mm Thick

Name: PCB Board Double Sided 1.6mm Thick
Brand: all-electronics-online.com
SKU: 823624935
Availability: InStock
Rating: 4.7 (134 reviews)

Price:	US $ 0.39/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC1325R3.8
Board Thick:	1.6mm
Surface Finish:	HASL Lead Free
Board Material:	Fr-4,
Number Of Layer:	2
Mininum Trace (Mil):	9.87
Minimum Gap(Mil):	7
Color Of Silkscreen:	White
Thickness Of Solder Mask:	13 Um
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V0

Product Description

Wholesale PCB board Circuit Board Double HASL Lead Free 1.6mm

Commodity Introduction
This is a type of FR-4 PCB for the application of CODEC. It's a 2 layer at 1.6mm base laminate
is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012 Class 2 using
supplied Gerber data. Each 10 boards or panels are packed separately.

Parameters & Data Sheet

Number of Layers	2
Board Type
Board Thickness	1.6mm +/-0.16
Board Material	FR-4
Board Material Supplier	ITEQ
Tg Value of Board Material	TG135ºC

PTH Cu thickness	≥20 um
Inner Iayer Cu thicknes	N/A
Surface Cu thickness	35 um (1oz)

Solder Mask Type and Model No.	LPSM, PSR-2000GT600D
Solder Mask Supplier	TAIYO
Solder Mask Colour	Green
Number of Solder Masks	2
Thickness of Solder Mask	13um

Type of Silkscreen Ink	IJR-4000 MW300
Supplier of Silkscreen	TAIYO
Color of Silkscreen	Whie
Number of Silkscreen	1

Mininum Trace (mil)	9.87 mil
Minimum Gap(mil)	7 mil

Surface Finish	HASL Lead free
RoHS Required	Yes
Warpage	0.15%

Thermal Shock Test	Pass, 288±5ºC,10 seconds, 3 cycles. No delamination, no blistering.
Solderablity Test	Pass, 255±5ºC,5 seconds Wetting Area Least 95%
Function	100% Pass electrical test
