PCB Board Immersion Gold Taconic Tla-35 0.762mm Halogen Free PCB
| Price: |
US $ 2.05/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-608-V6.08 |
| Final Foil External: |
1.0 Oz |
| Final Height Of PCB: |
1.0mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Green |
| Colour Of Component Legend: |
White |
| Mininum Trace (Mil): |
5.0 Mil |
| Minimum Gap(Mil): |
4.9 Mil |
| RoHS Required: |
Yes |
| Warpage: |
0.21% |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company Profile
An Experienced PCB Provider since 2003
Established in Shenzhen in 2003, Bicheng Enterprise Limited is an experienced PCB supplier.
We are widely-recognized and have a strong network in the PCB industry. As an ISO 9001-2008
-, ISO 14001-2004-, ISO/TS 16949:2009- and UL-compliant, we offer different types of PCB from
fiberglass, high frequency, metal core and ceramic. Our 16,000-square-meter factory can produce
30,000 square meters with 8,000 types of PCB per month.
Various PCBs are Available
Our extensive product line includes double-sided PCBs, multi-layer PCBs (up to 32 layers),
FR-4 PCBs (Tg130 - Tg170), high frequency PCBs (RO4350B, RO4003C), aluminum PCBs
(1W/MK, 2W/MK, 3W/MK), flexible PCBs and HDI PCB boards.
Having Multiple PCB Technology to Meet the Market Demands
Our plants use state-of-the-art equipment during our production and testing phase in order
to ensure quality and to meet the market demands. These include heavy copper testers,
impedance control testers, automatic target drill machines, PCB cleaning machines and
more.
Offering New Customer Promotion
For new customers, we offer SMT stencil foil, PCB panelization and prototype testing free of
charge.
Our other advantages include:- Our engineering design prevents problems from occurring during pre-production
- We can meet your PCB needs from prototype to mass volume production
- Eligible products rate of first production: >95%
- Delivery on time: >98%, door to door shipment service
- Customer complaint rate: <1%
Our advantages help you maximize your profit by saving time and cost. Contact us now.
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
RO4350B & RO4003C Data Sheets| Property | Typical Value | Direction | Units | Condition | Test
Method |
| | RO4003C | RO4350B | | | | |
Dielectric
Constant,
εr Process | 3.38±0.05 | 3.48±0.05 | Z | - | 10 GHz/
23ºC | IPC-TM-
650 2.5.5.5
Clampled
Stripline |
Dielectric
Constant,
εr Design | 3.55 | 3.66 | Z | - | 8 to 40
GHz | Differntial
Phase
Length
Method |
Dissipation
Factor
Tan, δ | 0.0027
0.0021 | 0.0037 0.0031 | Z | - | 10 GHz/
23ºC2.5
GHz/23ºC | IPC-TM-
650 2.5.5.5 |
Thermal
Coefficient
of εr | 40 | 50 | Z | ppm/ºC | minus 50ºC
to 150ºC | IPC-TM-
650 2.5.5.5 |
Volume
Resistivity | 1.7 x 10¹º | 1.2 x 10¹º | | MΩ·CM | COND A | IPC-TM-6
50 2.5.17.1 |
Surface
Resistivity | 4.2 x 10^9 | 5.7 x 10^9 | | MΩ | COND A | IPC-TM-
650 2.5.17.1 |
Electrical
Strenghth | 31.8 (780) | 31.2 (780) | Z | KV/mm
(V/mil) | 0.51mm
(0.020") | IPC-TM-
650 2.5.6.2 |
Tensile
Modulus | 19650
(2850)
19450
(2821) | 16767
(2432)
14153
(2053) | X Y | Mpa(ksi) | RT | ASTM D638 |
Tensile
Strength | 139(20.2)
100(14.5) | 203(29.5)
130(18.9) | X Y | Mpa(ksi) | RT | ASTM
D638 |
Flexural
Strength | 276 (40) | 255 (37) | | Mpa(kpsi) | | IPC-TM-
650
2.4.4 |
Dimensional
Stability | <0.3 | <0.5 | X,Y | mm/m
(mils/inch) | after etch
E2/150ºC | IPC-TM-
650
2.4.39A |
Coefficient
of Thermal
Expansion | 11 14 46 | 10 12 32 | X Y Z | ppm/ºC | minus 55ºC
to 288ºC | IPC-TM-
650 2.4.41 |
| Tg | >280 | >280 | | ºC TMA | A | IPC-TM-
650
2.4.24 |
| Td | 425 | 390 | | ºC TGA | | ASTM
D3850 |
Thermal
Conducvitity | 0.71 | 0.69 | | W/m/ºk | 80ºC | ASTM
C518 |
Moisture
Absorption | 0.06 | 0.06 | | % | 48 hrs
immersion
0.060"
sample
Temperature
50ºC | ASTM
D570 |
| Density | 1.79 | 1.86 | | gm/cm³ | 23ºC | ASTM
D792 |
Copper Peel
Strength | 1.05 (6.0) | 0.88 (5.0) | | N/mm (pli) | after solder
float 1 oz.
EDC Foil | IPC-TM-
650
2.4.8 |
| Flammability | N/A | V-0 | | | | UL 94 |
Lead-Free
Process
Compatible | Yes | Yes | | | | |
