PCB Board Tacoinc Tly-5 0.76mm (30 mil) Blind Via
| Price: |
US $ 1.99/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-558-V5.58 |
| Board Thick: |
1.6mm |
| Surface Finish: |
Immersion Gold |
| Out Layer Copper: |
35um (1 Oz) |
| Soldermask Color: |
Green, Taoyo, Lpsm, Psr-2000gt600d |
| Silkscreen Color: |
White, Taiyo, Ijr-4000 MW300 |
| Min Line Width: |
7 Mil |
| Min Line Spacing: |
4.9 Mil |
| Electrical Test: |
100% PCB Passed |
| Thermal Shock Test: |
Pass, No Delamination, No Blistering. |
| Solderability Test: |
Pass, 5 Seconds Wetting Area Least 95% |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Company ProfileBicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.
Variety of PCB technology to meet the market demands
HDI board
Heavy copper board
Hybrid material board
Blind via board
High frequency board
Metal core board
Immersion gold board
Multilayer board
Backplane board
Gold finger board
Printed Circuit Board
Aluminum PCB
High Frequency PCB
Flex PCB
Design For Manufacture| Serial NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 14 | Laminating | Tolerance of
laminate
thickness | ±10% PCB
thick | ±10% PCB
thick | ±8% PCB
thick |
| 15 | Maximum
laminate
thickness | 4.0mm | 6.0mm | 7.0mm |
| 16 | Laminate
alignment
accuracy | ≤±5 mil | ≤±4 mil | ≤±4 mil |
| 17 | Drill (18um, 35um,
70um etc are
finished copper.
If not mentioned
copper, finished
1oz is the default
value ) | Min.drill bit
diameter | 0.2 mm | 0.2 mm | 0.2 mm |
| 18 | Min.slot router
diameter | 0.60 mm | 0.60 mm | 0.60 mm |
| 19 | Min.tolerance
of PTH slots | ±0.15mm | ±0.15mm | ±0.1mm |
| 20 | Max.aspect ratio | 1:08 | 1:12 | 1:12 |
| 21 | Hole tolerance | ±3 mil | ±3 mil | ±3 mil |
| 22 | Space of via
to via | 6 mil(same
net),12 mil (different net) | 6 mil(same net),14 mil
(different net) | 4 mil(same net),
12 mil(different
net) |
| 23 | Space of
component
hole to
component hole | 12 mil(same
net),16 mil (different net) | 12 mil(same
net),16 mil (different net) | 10 mil(same
net),14 mil (different net) |
| 24 | Etching | Min.width of
etching logo | 10 mil(18 um),12 mil
(35 um),
12 mil(70 um) | 8 mil(18 um),
10 mil(35 um),
12 mil(70 um) | 6 mil(18 um),
8 mil(35 um),
12 mil(70 um) |
| 25 | Etch factor | 1.6-2.2 | 1.6-2.2 | 1.6-2.2 |
| 26 | Outer layer(18um,
35um, 70um etc
are finished copper.
If not mentioned
copper, finished
1oz is the default
value ) | Min.via pad
diameter | 20 mil | 16 mil | 16 mil |
| 27 | Min.BGA pad
diameter | 12 mil | 12 mil | 10 mil |
| 28 | Min.track and
spacing | 5/5 mil(18 um) | 4/4 mil(18 um) | 3/3.5 mil(18 um) |
| 5/5 mil(35 um) | 4/4 mil(35 um) | 3/4 mil(35 um) |
| 7/9 mil(70 um) | 6/8 mil(70 um) | 6/7 mil(70 um) |
| 9/11 mil(105 um) | 8/10 mil(105 um) | 8/9 mil(105 um) |
| 13/13 mil(140 um) | 12/12 mil(140 um) | 12/11 mil(140 um) |
| 29 | Minimum grid | 10/10 mil(35 um) | 8/8 mil(35 um) | 4/8 mil(35 um) |
| 30 | Min.space
(conductor
to pad, pad
to pad) | 6 mil(18 um) | 5 mil(18 um) | 4 mil(18 um) |
| 6 mil(35 um) | 5 mil(35 um) | 4 mil(35 um) |
| 9 mil(70 um) | 8 mil(70 um) | 7 mil(70 um) |
| 11 mil(105 um) | 10 mil(105 um) | 9 mil(105 um) |
| 13 mil(140 um) | 12 mil(140 um) | 11 mil(140 um) |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
