PCB Circuit 10 Layer Rogers Board RO4003 Fabrication

Name: PCB Circuit 10 Layer Rogers Board RO4003 Fabrication
Brand: all-electronics-online.com
SKU: 831304125
Availability: InStock
Rating: 4.7 (134 reviews)

Price:	US $ 2.05/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-456.1757-V1.1
Aluminum Core:	1W / Dielectric Material 75um
Thermal Resistance(°c/W):	<=0.45
Breakdown Voltage(VDC):	4000
Final Foil External:	1oz
Final Height Of PCB:	1.6mm
Surface Finish:	Hot Air Soldering Leveling(HASL), Lead Free
Solder Mask Color:	White, Taiyo Psr400 Wt02
Colour Of Component Legend:	Black
Via:	Non Plated Throught Hole (Npth)
Test:	100% Electrical Test Prior Shipment
Type:	Rigid Circuit Board
Flame Retardant Properties:	V0
Material:	Aluminum
Dielectric:	Aluminum 6061

Product Description

Company Profile
Bicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified

Aluminum PCB

High Frequency PCB

Flex PCB

PCB Circuit Board

Design For Manufacture

Serial NO.	Procedure	Item	Manufacturing capability
			Large volume (S<100 m²)	Middle volume (S<10 m²)	Prototype (S<1m²)
			Large volume (S<100 m²)	Middle volume (S<10 m²)	Prototype (S<1m²)
1	Inner layer (18um, 35um, 70um etc are finished copper. If not mentioned copper, finished 1oz is the default value )	Min.isolation of layers	0.1mm	0.1mm	0.06mm
2		Min.track and spacing	5/5mil(18um)	4/4mil(18um)	3/3.5mil (18um)
3			5/5mil(35um)	4/4mil(35um)	3/4mil (35um)
4			7/9mil(70um)	6/8mil(70um)	6/7mil (70um)
5			9/11mil(105um)	8/10mil (105um)	8/9mil (105um)
6			13/13mil(140um)	12/12mil (140um)	12/11mil (140um)
7		Min.distance from drill to conductor	4 Layer 10mil ,6 layer 10mil,8-12 layer 12mil	4 layer 8mil 6 layer 8mi 8-12 layer 1mil,14-20 layer 14mil 22-32 layer 18mil	4 layer 6mil, 6 layer 6mil, 8-14 layer 8mil,16-22 layer 12mil, 24-32 layer 14mil
8		Min.width of annular ring on inner layer	4 Layer 10mi l(35um),≥6 Layer 14mil(35um)	4 Layer 8mil(35um), ≥6 layer 12mil(35um)	4 Layer 6mil (35um),≥6 Layer 10mil (35um)
9		Inner layer isolation ring width(Min)	10mil (35um)	8mil (35um)	6mil (35um)
10		Min.via pad diameter	20mil (35um)	16mil (35um)	16mil (35um)
11		Min. distance from board edge to conductor(no copper exposured) (inner layer)	14 mil(35um)	12 mil (35um))	8 mil (35um)
12		Maximum copper weight(Inner layer and outer layer)	3 OZ( 105 um )	4 OZ ( 140 um )	6 OZ ( 210 um )
13		Core with different copper foil on both sides	/	18/35, 35/70 um	18/35, 35/70 um
