PCB Circuit 2 Layer with 0.8mm Thickness with RO4350b Material

PCB Circuit 2 Layer with 0.8mm Thickness with RO4350b Material
Price: US $ 0.95/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: BIC-110-V1.10
Final Foil External: 1 Oz
Final Height Of PCB: 0.8mm
Surface Finish: Immersion Gold
Solder Mask Color: Gloss Green
Colour Of Component Legend: White
Via: Plated Through Hole(Pth), Via Tented.
Minimum Trace And Space: 10 Mil/10 Mil
Minimum / Maximum Holes: 0.3/3.5mm
Board Plating: 0.0029"
Test: 100% Electrical Test
Type: Rigid Circuit Board
Flame Retardant Properties: V0
Dielectric: RO4350b 30mil (0.762mm) Tg 288
Material: Hydrocarbon/Woven Glass
Insulation Materials: Glass Reinforced Hydrocarbon

Product Description

Double Sided PCB High Frequency PCB Manufacturing RO4350B 30mil ENIG Applied In LNB


Commodity Introduction
This is a type of RO4350B PCB for the application of LNB. It's a 2 layer board at 0.8mm thick. The base laminate is from ROGERS CORP, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately


Parameters & Data Sheet
PCB SIZE62 x 57mm=1PCS
BOARD TYPE
Number of LayersDouble sided PCB
Surface Mount ComponentsYES
Through Hole ComponentsYES
LAYER STACKUPcopper ------- 17um(0.5oz)+plate TOP layer
RO4350B 30mil (0.762mm)
copper ------- 17um(0.5oz)+plate BOT Layer
TECHNOLOGY
Minimum Trace and Space:10mil/10mil
Minimum / Maximum Holes:0.3/3.5mm
Number of Different Holes:6
Number of Drill Holes:73
Number of Milled Slots:1
Number of Internal Cutouts:1
Impedance Controlno
BOARD MATERIAL
Glass Epoxy: RO4350B 30mil (0.762mm), Tg 288ºC
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.8mm ±0.1
PLATING AND COATING
Surface FinishImmersion gold 0.025µm over 3µm Nickel
Solder Mask Apply To: TOP and Bottom, 12micron Minimum
Solder Mask Color: Gloss Green, Taiyo PSR-2000GT600D
Solder Mas Type:LPSM
CONTOUR/CUTTINGRouting
MARKING
Side of Component LegendTOP
Colour of Component LegendWhite
Manufacturer Name or Logo: Marked on the board in a conductor
and leged FREE AREA
VIAPlated through hole(PTH), via tented.
FLAMIBILITY RATINGUL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension:  0.0059"
Board plating:0.0029"
Drill tolerance: 0.002"
TEST100% Electrical Test prior shipment
APPLICATION:Low Noise Block, LNB, Embedded Computer
Switching Adapter
GPS Data Logger
Role Based Access Control
TYPE OF ARTWORK TO BE SUPPLIEDemail file, Gerber RS-274-X, PCBDOC etc
SERVICE AREAWorldwide, Globally.
