PCB Circuit Board Black 10 Oz (350 um) Thick Copper
| Price: |
US $ 1.86/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-590-V5.90 |
| Final Foil External: |
1.0 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
Electroless Nickel Over Immersion Gold (Enig) |
| Solder Mask Color: |
Green, Psr-2000gt600d, Taiyo Supplied |
| Colour Of Component Legend: |
White, Ijr-4000 MW300, Taiyo Supplied |
| Mininum Trace (Mil): |
6.5 Mil |
| Minimum Gap(Mil): |
8 Mil |
| Board Plating: |
0.0030" (0.076mm) |
| Minimum / Maximum Holes: |
0.4/4.5mm |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
