PCB Circuit Board Hot Air Soldering Level RO4003c Plugged Vias
| Price: |
US $ 1.01/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-604-V6.04 |
| Board Thick: |
1.6mm |
| Surface Finish: |
HASL Lead Free |
| Out Layer Copper: |
35 Um (1 Oz) |
| Soldermask Color: |
Green |
| Silkscreen Color: |
White |
| Maximum Holes: |
4.2mm |
| Minimum Trace And Space: |
6.5 Mil/10.8 Mil |
| Via: |
Plated Through Hole(Pth) |
| Board Plating: |
0.0030" |
| Test: |
100% Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Company Profile
Founded in Shenzhen China in 2003, Bicheng Enterprise Limited is a professional PCB export
enterprise.
More than 14 years of PCB experiences
Excellent after-sales service
Substrate material: Epoxy glass (FR-4), High frequency, Metal core
Price advantages on circuit boards
Multilayer PCB and Hybrid material of Multilayer PCB
Focus on prototypes, small batches and volume production
TS16949 (2009), ISO14001 (2004), ISO9001 (2008), UL certified
Printed Circuit Board
Aluminum PCB
High Frequency PCB
Flex PCB
RO4350B & RO4003C Data Sheets| Property | Typical Value | Direction | Units | Condition | Test Method |
| | RO4003C | RO4350B | | | | |
Dielectric
Constant,
εr Process | 3.38±
0.05 | 3.48±0.05 | Z | - | 10 GHz/
23ºC | IPC-TM
-650
2.5.5.5
Clampled
Stripline |
Dielectric
Constant,
εr Design | 3.55 | 3.66 | Z | - | 8 to 40
GHz | Differntial
Phase
Length
Method |
Dissipation
Factor Tan,
δ | 0.0027 0.0021 | 0.0037 0.0031 | Z | - | 10 GHz/
23ºC
2.5 GHz/
23ºC | IPC-TM
-650
2.5.5.5 |
Thermal
Coefficient of
εr | 40 | 50 | Z | ppm/ºC | minus
50ºC
to
150ºC | IPC-TM
-650
2.5.5.5 |
Volume
Resistivity | 1.7 x 10¹º | 1.2 x 10¹º | | MΩ·CM | COND A | IPC-TM
-650
2.5.17.1 |
Surface
Resistivity | 4.2 x10^9 | 5.7 x 10^9 | | MΩ | COND A | IPC-TM
-650
2.5.17.1 |
Electrical
Strenghth | 31.8
(780) | 31.2 (780) | Z | KV/mm (V/mil) | 0.51mm
(0.020") | IPC-TM
-650
2.5.6.2 |
| Tensile Modulus | 19650
(2850)
19450
(2821) | 16767
(2432)
14153
(2053) | X Y | Mpa(ksi) | RT | ASTM
D638 |
| Tensile Strength | 139(20.2)
100(14.5) | 203
(29.5)
130
(18.9) | X Y | Mpa(ksi) | RT | ASTM
D638 |
| Flexural Strength | 276
(40) | 255 (37) | | Mpa(kpsi) | | IPC-TM
-650
2.4.4 |
Dimensional
Stability | <0.3 | <0.5 | X,Y | mm/m (mils/inch) | after etch
E2/150ºC | IPC-TM
-650
2.4.39A |
Coefficient of
Thermal Expansion | 11 14 46 | 1012 32 | X Y Z | ppm/ºC | minus
55ºC
to 288ºC | IPC-TM
-650
2.4.41 |
| Tg | >280 | >280 | | ºC TMA | A | IPC-TM
-650
2.4.24 |
| Td | 425 | 390 | | ºC TGA | | ASTM
D3850 |
Thermal
Conducvitity | 0.71 | 0.69 | | W/m/ºk | 80ºC | ASTM
C518 |
Moisture
Absorption | 0.06 | 0.06 | | % | 48 hrs
immersion
0.060"
sample
Temperature
50ºC | ASTM
D570 |
| Density | 1.79 | 1.86 | | gm/cm³ | 23ºC | ASTM
D792 |
Copper Peel
Strength | 1.05 (6.0) | 0.88 (5.0) | | N/mm (pli) | after solder
float 1 oz.
EDC Foil | IPC-TM
-650
2.4.8 |
| Flammability | N/A | V-0 | | | | UL 94 |
Lead-Free Process
Compatible | Yes | Yes | | | | |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
