Name: PCB Circuit Double Sided PCB 0.8mm Board
Brand: all-electronics-online.com
SKU: 823620365
Availability: InStock
Rating: 4.8 (91 reviews)

Price:	US $ 0.40/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC1322R1.2
Board Thick:	0.8
Surface Finish:	HASL Lead Free
Board Material:	Fr4
Surface Cu Thickness:	35
Solder Mask Colour:	Green
Number Of Solder Masks:	2
Thickness Of Solder Mask:	13 Um
Color Of Silkscreen:	White
Test:	Electronic Test
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V0

Product Description

Pcb Circuit Double Sided PCB 0.8mm PCB board

Commodity Introduction
This is a type of FR-4 PCB for the application of CODEC. It's a 2 layer board at 0.8mm thick. The
base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012
Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.

Parameter & Data Sheet

Number of Layers	2
Board Type	Double Sided PCB
Board Thickness	0.8mm +/-0.08
Board Material	FR-4
Board Material Supplier	ITEQ
Tg Value of Board Material	TG135ºC

PTH Cu thickness	≥20 um
Inner Iayer Cu thicknes	N/A
Surface Cu thickness	35 um (1oz)

Solder Mask Type and Model No.	LPSM, PSR-2000GT600D
Solder Mask Supplier	TAIYO
Solder Mask Colour	Green
Number of Solder Masks	2
Thickness of Solder Mask	13um

Type of Silkscreen Ink	IJR-4000 MW300
Supplier of Silkscreen	TAIYO
Color of Silkscreen	Whie
Number of Silkscreen	1

Mininum Trace (mil)	4 mil
Minimum Gap(mil)	4 mil

Surface Finish	HASL Lead free
RoHS Required	Yes
Warpage	0.18%

Thermal Shock Test	Pass, 288±5ºC,10 seconds, 3 cycles. No delamination, no blistering.
Solderablity Test	Pass, 255±5ºC,5 seconds Wetting Area Least 95%
Function	100% Pass electrical test
Workmanship	Compliance with IPC-A-600H & IPC-6012C Class 2
