PCB Double Sided High Quality Immersion Gold with 1.00mm
| Price: |
US $ 1.00/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-489.1757-V1.1 |
| Outer Copper Foil: |
1oz |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Black, Kuang Shun, Lpsm, Ksm-S6189bk31 |
| Thickness Of Solder Mask: |
13um |
| Minimum Trace And Space: |
9.6mil |
| Minimum Gap(Mil): |
5.9mil |
| Test: |
100% Electrical Test Prior Shipment |
| Surface Cu Thickness: |
1oz(35um) |
| Board Thickness: |
1.0mm +/-0.1 |
| Tg Value Of Board Material: |
150ºC |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
| Brand: |
Bicheng |
Product Description
Parameters & Data Sheet| Number of Layers | 2 |
| Board Type | Double Sided PCB |
| Board Thickness | 1.0mm +/-0.1 |
| Board Material | FR-4 |
| Board Material Supplier | ITEQ |
| Tg Value of Board Material | 150ºC |
| |
| PTH Cu thickness | ≥20um (See hole wall details) |
| Inner Iayer Cu thicknes | N/A |
| Surface Cu thickness | 35 um (1oz) |
| |
| Solder Mask Type and Model No. | LPSM, KSM-S6189BK31 |
| Solder Mask Supplier | KUANG SHUN |
| | Black |
| Number of Solder Masks | 2 |
| Thickness of Solder Mask | 13um |
| |
| Type of Silkscreen Ink | N/A |
| Supplier of Silkscreen | N/A |
| Color of Silkscreen | N/A |
| Number of Silkscreen | N/A |
| |
| Mininum Trace (mil) | 9.6mil |
| Minimum Gap(mil) | 5.9mil |
| |
| Surface Finish | HASL Lead Free |
| RoHS Required | Yes |
| Warpage | 0.25% |
| |
| Thermal Shock Test | Pass, 288±5ºC,10 seconds, 3 cycles. No delamination, no blistering. |
| Solderablity Test | Pass, 255±5ºC,5 seconds Wetting Area Least 95% |
| Function | 100% Pass electrical test |
| Workmanship | Compliance with IPC-A-600H & IPC-6012C Class 2 |
