PCB OEM Black Circuit Board 6 Oz (210 um) Prototype Service
| Price: |
US $ 1.2/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-588-V5.88 |
| Board Thickness: |
0.20mm |
| Tg Value Of Board Material: |
60ºC |
| Surface Cu Thickness: |
35µm (1 Oz) |
| Coverlay Colour: |
Yellow |
| Stiffener Thickness: |
0.2mm |
| Color Of Silkscreen: |
White |
| Surface Finish: |
Immersion Gold |
| Peeling Test Of Coverlay: |
No Peelable |
| RoHS Required: |
Yes |
| Function: |
100% Pass Electrical Test |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Application of Antenna |
| Insulation Materials: |
Polyimide |
Product Description
Company ProfileBicheng Enterprise Limited which was founded in Shenzhen China in 2003 is a professional PCB
export enterprise. We have established a good relationship of cooperation with well-known
enterprises in the same industry. Our PCB products range from fiberglass PCB, high frequency
PCB to metal core PCB and ceramic PCB's. This is a unique printed circuit board supplier and
export enterprise. She has groups of skilled manufacturing facilities just like the experienced
football players in the football field and every batch of shipment is like a beautiful gift transmitted
to your hands.
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Design For ManufacturabilityThis manufacturability guide provides an overview of various areas that printed circuit board
designer may take into consideration on the fabrication possibility, manufacturing cost and
reliability of their products. This DFM is divided into 5 parts for our readers. | Serial NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 1 | Inner layer (18um,
35um, 70um etc
are finished copper.
If not mentioned
copper, finished
1oz is the default
value ) | Min.isolation
of layers | 0.1mm | 0.1mm | 0.06mm |
| 2 | Min.track
and spacing | 5/5 mil
(18 um) | 4/4 mil(18 um) | 3/3.5 mil
(18 um) |
| 3 | 5/5 mil
(35 um) | 4/4 mil(35 um) | 3/4 mil
(35 um) |
| 4 | 7/9 mil
(70 um) | 6/8 mil(70 um) | 6/7 mil
(70 um) |
| 5 | 9/11 mil
(105 um) | 8/10 mil(105 um) | 8/9 mil
(105 um) |
| 6 | 13/13 mil
(140 um) | 12/12 mil(140 um) | 12/11 mil
(140 um) |
| 7 | Min.distance
from drill to
conductor | 4 Layer 10 mil,6 layer
10 mil,8-12 layer
12 mil | 4 layer 8 mil,6 layer
8 mil,8-12 layer 10 mil,
14-20 layer 14 mil,
22-32 layer 18 mil | 4 layer
6 mil,6 layer
6 mil,8-14 layer
8 mil,16-22 layer
12 mil,
24-32
layer 14 mil |
| 8 | Min.width of
annular ring
on inner layer | 4 Layer
10mil
(35um),
≥6 Layer
14mil
(35um) | 4 Layer 8 mil(35u m),
≥6 layer 12 mil(35 um) | 4 Layer
6 mil(35 um),≥6
Layer
10 mil
(35 um) |
| 9 | Inner layer
isolation ring
width(Min) | 10mil
(35um) | 8 mil
(35 um) | 6 mil
(35 um) |
| 10 | Min.via pad
diameter | 20mil
(35um) | 16 mil
(35 um) | 16 mil
(35 um) |
| 11 | Min. distance
from board
edge to
conductor
(no copper
exposured)
(inner layer) | 14 mil
(35um) | 12 mil
(35 um)) | 8 mil
(35 um) |
| 12 | Maximum
copper weight
(Inner layer and
outer layer) | 3 OZ
(105 um ) | 4 OZ
( 140 um ) | 6 OZ
( 210 um ) |
| 13 | Core with
different copper
foil on both sides | / | 18/35,
35/70 um | 18/35,
35/70 um |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
More >
Other Products with This Manufacturers
