Plated Radii (Castellation) PCB Circuit Board 1.8mm Thick 0.071" PCB
| Price: |
US $ 1.06/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-639-V6.39 |
| Board Thick: |
1.6mm |
| Surface Finish: |
Immersion Gold |
| Out Layer Copper: |
35 Um (1 Oz) |
| Soldermask Color: |
Green |
| Silkscreen Color: |
White |
| Inner Copper Thickness: |
0.5 Oz, 1 Oz |
| Impedance Control: |
Single Trace, 50ohm, Differential Pairs, 100ohm |
| Minimum / Maximum Holes: |
0.3/4.6mm |
| Minimum Trace And Space: |
4 Mil/4 Mil |
| Test: |
100% Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Company Profile
The manufacturing facilities are independent industrial plant. There're 16000 square meters
workshop area. Brand new automatic equipment was introduced from Israel, Germany, Japan
and Taiwan area. As of now the manufacturing capability for 2-12 layer PCBs covers 300
thousand square feet per month. 7000-8000 types of different PCBs are shipped to worldwide
each month.
PRODUCTS & SERVICES
a) FR-4 TG>135, High TG>170, High CTI>600V
b) RO4350B, RO4003C, F4B microwave material
c) Aluminum based PCB, 1W/MK-3W/MK material
d) Layer Count up to 32 layers
e) Heavy Copper
f) Hybrid Material Multilayer PCB
g) Impedance Controlled PCB
h) HASL Lead free, Electroless Nickle Immersion Gold (ENIG), Immersion Silver, Immersion Tin,
OSP
i) Color of Solder Mask: Green, Blue, Matt Blue, Yellow, Black, Red and White etc.
j) Special holes: blind via, countersink hole, castellation hole, press-fit hole
k) Quick turn-around (QTA) Delivery
l) Minimum Order Quantity (MOQ) 1 pcs
m) Door to Door shipment service
SERVICE AREA
North America, Oceania, Southeast Asia, Eastern Europe, Africa, Latin America, Western &
Southern Europe, Northern Europe, Central & South Asian, Middle East.
Printed Circuit Board
Aluminum PCB
High Frequency PCB
Flex PCB
Technology Information
ITEQ Laminate/ Prepreg : IT-180ATC / IT-180ABS
IPC-4101C Spec / 99 / 101 / 126
LAMINATE( IT-180ATC)| Property | Thickness
<0.50 mm | Thickness
>=0.50 mm | Units | Test
Method |
| [0.0197 in] | [0.0197 in] |
| Typical Value | Spec | Typical Value | Spec | Metric | IPC-TM
-650 |
| (English) | (or as
noted) |
Peel Strength,
minimum | | | | | N/mm | 2.4.8 |
A. Low profile
copper foil and
very low profile
copper foil - all
copper weights
> 17mm [0.669
mil] | | | | | (lb/inch) | 2.4.8.2 |
B. Standard
profile copper
foil | 0.88 (5.0) | 0.70 (4.00) | 0.88 (5.0) | 0.70 (4.00) | | 2.4.8.3 |
1. After
Thermal Stress | | | | | | |
2. At 125°C
[257 F] | | | | | | |
3. After
Process
Solutions | 1.23 (7.0) | 0.80 (4.57) | 1.40 (8.0) | 1.05 (6.00) | | |
| | 1.05 (6.0) | 0.70 (4.00) | 1.23 (7.0) | 0.70 (4.00) | | |
| | 1.05 (6.0) | 0.55 (3.14) | 1.23 (7.0) | 0.80 (4.57) | | |
Volume
Resistivity,
minimum | | | | | MW-cm | 2.5.17.1 |
A. C-96/
35/90 | 3.0x1010 | 106 | -- | -- |
B. After
moisture
resistance | -- | -- | 3.0x1010 | 104 |
C. At elevated
temperature E-
24/125 | 5.0x1010 | 103 | 1.0x1010 | 103 |
Surface
Resistivity,
minimum | | | | | MW | 2.5.17.1 |
A. C-96/
35/90 | 3.0x1010 | 104 | -- | -- |
B. After
moisture
resistance | -- | -- | 3.0x1010 | 104 |
C. At elevated
temperature
E-24/125 | 4.0x1010 | 103 | 4.0x1010 | 103 |
Moisture
Absorption,
maximum | -- | -- | 0.12 | 0.8 | % | 2.6.2.1 |
Dielectric
Breakdown,
minimum | -- | -- | 60 | 40 | kV | 2.5.6 |
Permittivity
(Dk, 50%
resin content) | | 5.4 | | 5.4 | -- | |
(Laminate &
Laminated
Prepreg) | | | |
| A. 1MHz | 4.4 | 4.4 | 2.5.5.9 |
| B. 1GHz | 4.4 | 4.4 | |
| C. 2GHz | 4.2 | 4.3 | 2.5.5.13 |
| D. 5GHz | 4.1 | 4.1 | |
| E. 10GHz | 4 | 4.1 | |
Loss Tangent
(Df, 50% resin
content) | | 0.035 | | 0.035 | -- | |
(Laminate &
Laminated
Prepreg) | | | |
| A. 1MHz | 0.015 | 0.014 | 2.5.5.9 |
| B. 1GHz | 0.015 | 0.015 | |
| C. 2GHz | 0.015 | 0.015 | 2.5.5.13 |
| D. 5GHz | 0.016 | 0.016 | |
| E. 10GHz | 0.017 | 0.016 | |
Flexural
Strength,
minimum | | | | | N/mm2 | 2.4.4 |
A. Length
direction | -- | -- | 500-530 | 415 | (lb/in2) |
| | -- | -- | (72,500-76,850) | -60,190 | |
B. Cross
direction | -- | -- | 410-440 | 345 | |
| | -- | -- | (59,450-63,800) | -50,140 | |
Arc
Resistance,
minimum | 125 | 60 | 125 | 60 | s | 2.5.1 |
Thermal
Stress 10 s
at 288°C
[550.4F],
minimum | | | | | Rating | 2.4.13.1 |
| A. Unetched | Pass | Pass Visual | Pass | Pass Visual |
| B. Etched | Pass | Pass Visual | Pass | Pass Visual |
Electric
Strength,
minimum | 45 | 30 | -- | -- | kV/mm | 2.5.6.2 |
(Laminate &
Laminated
Prepreg) |
| Flammability, | V-0 | V-0 | V-0 | V-0 | Rating | UL94 |
(Laminate &
Laminated
Prepreg) |
Glass
Transition
Temperature
(DSC) | 175 | 170 minimum | 175 | 170 minimum | ˚C | 2.4.25 |
Decomposition
Temperature | -- | -- | 345 | 340 minimum | ˚C | 2.4.24.6 |
(5%
wt
loss) |
X/Y Axis CTE
(40ºC to 125ºC) | -- | -- | 10--13 | -- | PPM/˚C | 2.4.24 |
| Z-Axis CTE | | | | | | 2.4.24 |
| A. Alpha 1 | -- | -- | 45 | 60 maximum | PPM/˚C |
| B. Alpha 2 | -- | -- | 210 | 300 maximum | PPM/˚C |
C. 50 to
260 Degrees
C | -- | -- | 2.7 | 3.0 maximum | % |
Thermal
Resistance | | | | | | 2.4.24.1 |
| A. T260 | -- | -- | >60 | 30 minimum | Minutes |
| B. T288 | -- | -- | >30 | 15 minimum | Minutes |
CAF
Resistance | -- | -- | Pass | AABUS | Pass/Fail | 2.6.25 |
