| Prod Model: |
BJP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Place Of Origin: |
Wenzhou,China |
| Brand Name: |
B&J |
| Model Number: |
Bjp |
| Thickness: |
1.2mm,1.5mm,2.0mm |
| Paint Finish: |
Epoxy Polyester Coating |
| Color: |
Ral7035 or Ral7032 |
| Certificate: |
Ce,IEC,RoHS,TUV,SGS |
| Customised Size: |
Accepted |
| Lock: |
Himel Type or Available on Request |
| SGS: |
Audited Supplier |
| Type: |
Distribution Box |
| Size: |
200X200X150mm to 1200X1200X600mm |
| Shell Protection Grade: |
IP65 |
| Brand: |
B&J |
Product Description
Material:
Sheet steel
Enclosure: 1.2mm
Door: 1.2mm
Mounting plate: 2.0mm
Surface finish:
Enclosure and door: Dipcoat-primed, powder-coated in textured Ral7032 or Ral7035 outside
Mounting plate: RAL2000 or galvanized
Protection:
Protection degree: IP66
Impact resistaance: IK10
Supply includes:
Enclosure & clear door
Gland plate with sealing gasket, lock, Accessories
Warranty Service:
We 100% Gurantee your Satisfaction
1 Pls report us if there are any problem, we will solve it ASAP.
2 This items comes with 1 YEAR warranty.
Equivalent replacements can be provided with shipment of your next order if the products are broken for unartificial factors within 1 YEAR; However photos are needed for us to find the factors of damaging them.
3 Shipping and handling fees are not refundable for return or exchange items.
Our Advantages:
1.20 year's OEM & ODM experience
2. Spain Design
3. The color can remain for over 5 years
4. Professional team
Philosophy of the Company:
Excellent design, Excellent make. Excellent service
| Height | Width | Depth | Reference |
| 250 | 200 | 150 | BJS1-2520/150 |
| 300 | 250 | 150 | BJS1-3025/150 |
| 300 | 250 | 200 | BJS1-3025/200 |
| 300 | 300 | 150 | BJS1-33/150 |
| 300 | 300 | 200 | BJS1-33/200 |
| 300 | 400 | 200 | BJS1-34/200 |
| 400 | 300 | 150 | BJS1-43/150 |
| 400 | 300 | 200 | BJS1-43/200 |
| 400 | 400 | 200 | BJS1-44/200 |
| 400 | 600 | 250 | BJS1-46/250 |
| 400 | 600 | 300 | BJS1-46/300 |
| 500 | 400 | 150 | BJS1-54/150 |
| 500 | 400 | 200 | BJS1-54/200 |
| 500 | 400 | 250 | BJS1-54/250 |
| 500 | 500 | 250 | BJS1-55/250 |
| 600 | 400 | 150 | BJS1-64/150 |
| 600 | 400 | 200 | BJS1-64/200 |
| 600 | 400 | 250 | BJS1-64/250 |
| 600 | 500 | 150 | BJS1-65/150 |
| 600 | 500 | 200 | BJS1-65/200 |
| 600 | 500 | 250 | BJS1-65/250 |
| 600 | 600 | 250 | BJS1-66/250 |
| 600 | 600 | 300 | BJS1-66/300 |
| 600 | 800 | 300 | BJS1-68/300 |
| 700 | 500 | 200 | BJS1-75/200 |
| 700 | 500 | 250 | BJS1-75/250 |
| 800 | 600 | 200 | BJS1-86/200 |
| 800 | 600 | 250 | BJS1-86/250 |
| 800 | 600 | 300 | BJS1-86/300 |
| 800 | 600 | 400 | BJS1-86/400 |
| 800 | 800 | 200 | BJS1-88/200 |
| 800 | 800 | 300 | BJS1-88/300 |
| 800 | 1000 | 300 | BJS1-810/300 |
| 1000 | 600 | 250 | BJS1-106/250 |
| 1000 | 600 | 300 | BJS1-106/300 |
| 1000 | 800 | 250 | BJS1-108/250 |
| 1000 | 800 | 300 | BJS1-108/300 |
| 1000 | 800 | 400 | BJS1-108/400 |
| 1000 | 1000 | 300 | BJS1-1010/300 |
| 1000 | 1200 | 300 | BJS1-1012/300 |
| 1200 | 800 | 300 | BJS1-128/300 |
| 1200 | 800 | 400 | BJS1-128/400 |
| 1200 | 1000 | 300 | BJS1-1210/300 |
| Height | Width | Depth | Reference |
| 250 | 200 | 150 | BJS1-2520/150 |
| 300 | 250 | 150 | BJS1-3025/150 |
| 300 | 250 | 200 | BJS1-3025/200 |
| 300 | 300 | 150 | BJS1-33/150 |
| 300 | 300 | 200 | BJS1-33/200 |
| 300 | 400 | 200 | BJS1-34/200 |
| 400 | 300 | 150 | BJS1-43/150 |
| 400 | 300 | 200 | BJS1-43/200 |
| 400 | 400 | 200 | BJS1-44/200 |
| 400 | 600 | 250 | BJS1-46/250 |
| 400 | 600 | 300 | BJS1-46/300 |
| 500 | 400 | 150 | BJS1-54/150 |
| 500 | 400 | 200 | BJS1-54/200 |
| 500 | 400 | 250 | BJS1-54/250 |
| 500 | 500 | 250 | BJS1-55/250 |
| 600 | 400 | 150 | BJS1-64/150 |
| 600 | 400 | 200 | BJS1-64/200 |
| 600 | 400 | 250 | BJS1-64/250 |
| 600 | 500 | 150 | BJS1-65/150 |
| 600 | 500 | 200 | BJS1-65/200 |
| 600 | 500 | 250 | BJS1-65/250 |
| 600 | 600 | 250 | BJS1-66/250 |
| 600 | 600 | 300 | BJS1-66/300 |
| 600 | 800 | 300 | BJS1-68/300 |
| 700 | 500 | 200 | BJS1-75/200 |
| 700 | 500 | 250 | BJS1-75/250 |
| 800 | 600 | 200 | BJS1-86/200 |
| 800 | 600 | 250 | BJS1-86/250 |
| 800 | 600 | 300 | BJS1-86/300 |
| 800 | 600 | 400 | BJS1-86/400 |
| 800 | 800 | 200 | BJS1-88/200 |
| 800 | 800 | 300 | BJS1-88/300 |
| 800 | 1000 | 300 | BJS1-810/300 |
| 1000 | 600 | 250 | BJS1-106/250 |
| 1000 | 600 | 300 | BJS1-106/300 |
| 1000 | 800 | 250 | BJS1-108/250 |
| 1000 | 800 | 300 | BJS1-108/300 |
| 1000 | 800 | 400 | BJS1-108/400 |
| 1000 | 1000 | 300 | BJS1-1010/300 |
| 1000 | 1200 | 300 | BJS1-1012/300 |
| 1200 | 800 | 300 | BJS1-128/300 |
| 1200 | 800 | 400 | BJS1-128/400 |
| 1200 | 1000 | 300 | BJS1-1210/300 |
