PMDC Spur Gear Motor for Equipment

Name: PMDC Spur Gear Motor for Equipment
Brand: all-electronics-online.com
SKU: 774788415
Availability: InStock
Rating: 4.4 (112 reviews)

Price:	US $ 25piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	60ZYT105-60SPGS50
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Power Tools
Operating Speed:	Constant Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brush
Certification:	CE

Product Description

Gearbox with diameter 60mm, allowed torque 5N.m
Fit for alloy steel gears, all bearing configuration, low noise.

Motor Technical Data

Model	Rated Voltage (VDC)	No-load Speed (r/min)	No-load Current (mA)	Rated Speed (r/min)	Rated Torque (mN.m)	Output Power (W)	Pated Current (mA)	Stall Torque (mN.m)	Stall Current (A)
60ZYT105-2420	24	2000	0.32	1550	125	20	1.6	0.55	6.0
60ZYT105-2430	24	3000	0.40	2500	120	30	2.2	0.72	10.8

Gear motor Technical Data

Reduction ratio	3	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40
Number of grea trains	2	2	2	2	2	2	2	2	2	3	3	3	3	3
Length(L) mm	32	32	32	32	32	32	32	32	32	40	40	40	40	40
No-load speed r/min	667	400	333	267	222	200	160	200	111	100	80	67	56	50
Rated speed r/min	517	310	258	207	172	155	124	167	86	77	62	52	43	39
Rated torque N.m	0.30	0.50	0.61	0.76	0.91	1.0	1.2	1.4	1.8	1.8	2.3	2.7	3.3	3.6
Max.permissible load in a short time	5.0	5.0	5.0	5.0	5.0	5.0	5.0	5.0	5.0	10.0	10.0	10.0	10.0	10.0
Direction of Rotation	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CW	CW	CW	CW	CW

Reduction ratio	3	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40
Number of grea trains	2	2	2	2	2	2	2	2	2	3	3	3	3	3
Length(L) mm	32	32	32	32	32	32	32	32	32	40	40	40	40	40
No-load speed r/min	1000	600	500	400	333	300	240	200	167	150	120	100	83	75
Rated speed r/min	833	500	417	333	278	250	200	167	139	125	100	83	69	62
Rated torque N.m	0.29	0.48	0.58	0.73	0.87	0.97	1.2	1.4	1.7	1.7	2.2	2.6	3.1	3.5
N.m Max.permissible load in a short time	5.0	5.0	5.0	5.0	5.0	5.0	5.0	5.0	5.0	10.0	10.0	10.0	10.0	10.0
Direction of Rotation	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CCW	CW	CW	CW	CW	CW

The specifications can be designed according to the customer's requirement !
