Polyimide PCB 25um 1.8mm Thick 0.071" Circuit Board
| Price: |
US $ 0.96/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-696-V6.96 |
| Board Thick: |
1.6mm |
| Surface Finish: |
Immersion Gold |
| Out Layer Copper: |
35 Um (1 Oz) |
| Soldermask Color: |
Green |
| Silkscreen Color: |
White |
| Minimum Trace And Space: |
8.3 Mil/8.3 Mil |
| Minimum / Maximum Holes: |
0.52/4.0mm |
| Via: |
Plated Through Hole(Pth) |
| Board Plating: |
0.0030" |
| Test: |
100% Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Company ProfileThe manufacturing facilities are independent industrial plant. There're 16000 square meters
workshop area. Brand new automatic equipment was introduced from Israel, Germany, Japan
and Taiwan area. As of now the manufacturing capability for 2-12 layer PCBs covers 300 thou
-sand square feet per month. 7000-8000 types of different PCBs are shipped to worldwide each
month.
PRODUCTS & SERVICES
a) FR-4 TG>135, High TG>170, High CTI>600V
b) RO4350B, RO4003C, F4B microwave material
c) Aluminum based PCB, 1W/MK-3W/MK material
d) Layer Count up to 32 layers
e) Heavy Copper
f) Hybrid Material Multilayer PCB
g) Impedance Controlled PCB
h) HASL Lead free, Electroless Nickle Immersion Gold (ENIG), Immersion Silver, Immersion Tin,
OSP
i) Color of Solder Mask: Green, Blue, Matt Blue, Yellow, Black, Red and White etc.
j) Special holes: blind via, countersink hole, castellation hole, press-fit hole
k) Quick turn-around (QTA) Delivery
l) Minimum Order Quantity (MOQ) 1 pcs
m) Door to Door shipment service
SERVICE AREA
North America, Oceania, Southeast Asia, Eastern Europe, Africa, Latin America, Western &
Southern Europe, Northern Europe, Central & South Asian, Middle East.
Printed Circuit Board
Aluminum PCB
High Frequency PCB
Flex PCB
Technology InformationITEQ Laminate/ Prepreg : IT-140TC / IT-140BS
IPC-4101A Spec / 21
LAMINATE(IT-140TC)| Property | Thickness<0.50 mm | Thickness>=0.50 mm | Units | Test
Method |
| [0.0197 in] | [0.0197 in] |
Typical
Value | Spec | Typical
Value | Spec | Metric | IPC-TM
-650 |
| (English) | (or as
noted) |
Peel Strength,
minimum | | | | | N/mm | 2.4.8 |
A. Low profile
copper foil and
very low profile
copper foil - all
copper weights
> 17mm [0.669
mil] | | | | | (lb/inch) | 2.4.8.2 |
B. Standard
profile copper
foil | 0.96 (5.5) | 0.70 (4.0) | 0.96 (5.5) | 0.70 (4.0) | | 2.4.8.3 |
1. After
Thermal
Stress | | | | | | |
2. At
125°C
[257 F] | | | | | | |
3. After
Process
Solutions | 1.75 (10 ) | 0.80 (4.57) | 1.93 (11.0) | 1.05 (6.00) | | |
| | 1.66 (9.5) | 0.70 (4.00) | 1.66 (9.5) | 0.70 (4.00) | | |
| | 1.49 (8.5) | 0.55 (3.14) | 1.49 (8.5) | 0.80 (4.57) | | |
Volume
Resistivity,
minimum | | | | | MW-cm | 2.5.17.1 |
| A. C-96/35/90 | 5x1010 | 106 | -- | -- |
B. After
moisture
resistance | -- | -- | 5x1010 | 104 |
C. At elevated
temperature
E-24/125 | 5x1010 | 103 | 5x1010 | 103 |
Surface
Resistivity,
minimum | | | | | MW | 2.5.17.1 |
| A. C-96/35/90 | 3.5x1010 | 104 | -- | -- |
B. After
moisture
resistance | -- | -- | 3.5x1010 | 104 |
C. At elevated
temperature
E-24/125 | 6x1010 | 103 | 6x1010 | 103 |
Moisture
Absorption,
maximum | 0.3 | -- | 0.1 | 0.8 | % | 2.6.2.1 |
Dielectric
Breakdown,
minimum | -- | -- | 60 | 40 | kV | 2.5.6 |
Permittivity
(Dk, 50%
resin content) | 4.6 | 5.4 | 4.6 | 5.4 | -- | 2.5.5.9 |
(Laminate &
Laminated
Prepreg) |
| A. 1MHz |
Loss Tangent
(Df, 50% resin
content) | 0.016 | 0.035 | 0.016 | 0.035 | -- | 2.5.5.9 |
(Laminate &
Laminated
Prepreg) |
| A. 1MHz |
Flexural
Strength,
minimum | | | | | N/mm2 | 2.4.4 |
A. Length
direction | -- | -- | 500-530 | 415 | (lb/in2) |
| | -- | -- | (72,500-76,850) | -60,190 | |
B. Cross
direction | -- | -- | 430-460 | 345 | |
| | -- | -- | (62,350-66,700) | -50,140 | |
Arc Resistance,
minimum | 120 | 60 | 120 | 60 | s | 2.5.1 |
Thermal Stress
10 s at 288°C
[550.4F],
minimum | | | | | Rating | 2.4.13.1 |
| A. Unetched | Pass | Pass
Visual | Pass | Pass
Visual |
| B. Etched | Pass | Pass
Visual | Pass | Pass
Visual |
Electric Strength,
minimum | 45 | 30 | -- | -- | kV/mm | 2.5.6.2 |
(Laminate &
Laminated
Prepreg) |
| Flammability, | V-0 | V-0 | V-0 | V-0 | Rating | UL94 |
(Laminate &
Laminated
Prepreg) |
Glass Transition
Temperature
(DSC) | 140 | 135 minimum | 140 | 135 minimum | ˚C | 2.4.25 |
Decomposition
Temperature | -- | -- | 305 | -- | ˚C | 2.4.24.6 |
(5% wt
loss) |
| Z-Axis CTE | | | | | | 2.4.24 |
| A. Alpha 1 | -- | -- | 55 | -- | ppm/˚C |
| B. Alpha 2 | -- | -- | 290 | -- | ppm/˚C |
C. 50 to
260
Degrees
C | -- | -- | 4.2 | -- | % |
Thermal
Resistance | | | | | | 2.4.24.1 |
| A. T260 | -- | -- | 15 | -- | Minutes |
| B. T288 | -- | -- | 2 | -- | Minutes |
CAF
Resistance | -- | -- | Pass | AABUS | Pass/Fail | 2.6.25 |
