Porcelain Expulsion Fuse Cutout / Dropout Fuse

Name: Porcelain Expulsion Fuse Cutout / Dropout Fuse
Brand: all-electronics-online.com
SKU: 738128285
Availability: InStock
Rating: 4.3 (96 reviews)

Price:	US $ 8.9-30.2/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	3/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	HXM-2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage 15kv:	Rated Current up to 100/200A
Breaking Capacity:	High
Standard:	IEC282-1
Type:	Cut out Fuse
Usaga:	Outdoor High Voltage Electrical System

Product Description

Product Description

Export types porcelain power cutout fuse is of outdoor used high voltage protective device. To be connect with incoming feeder of distribution transformer or distribution lines. HXM series mainly protect transformer or lines from short circuit and over load, and on/off loading current.

Basic information:

Model number: HXM-2 Type: Fuse
Rated Voltage: 15kv Rate current: 100A/200A
Breaking Current: 6300A/12500A Impulse Voltage: 125BIL
Leakage Distance: 400mm Sample: Available

Wenzhou Shuguang Fuse Co., Ltd is a manufacturer of electric appliances with well-equipped testing equipment and strong technical force.

With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in electrical industry and other industries.

Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

We welcome new and old customers from all over world to contact us for future business relationships and achieving mutual success!
