Preventing Time Relay

Name: Preventing Time Relay
Brand: all-electronics-online.com
SKU: 756518535
Availability: InStock
Rating: 4.4 (92 reviews)

Price:	US $ 3-4/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	APR-3
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimensions:	504058
Surface Type Mounting Socket:	PF083A(E) PF085A
Flush Type Mounting Socket:	P3g-08 Us-08
Mechanical Life:	5*10^6times
Electrical Life:	10^5times
Ambient Temperature:	-10°c~+55°c
Ambient Humidity:	45-85%Rh
Power Consumption:	2va

Product Description

Classification		Preventing Relay
Model		APR-3	JVM-1
Dimension		50 H x 40W x 58D	61H x 49W x 70D
Mounting Socket	Surface type	PF083A(E)PF085A	PS-08PF083A(E)
	Flush type	P3G-08 US-08	-
Function		Prevent the three-phase induction motor works reversely and works in high voltageGuarantee the load effectively
Operating voltage		-	-
Rated voltage		-	-
Delay time range		-	-
Delaying control precision		-	-
Time limit(1C)		10A	10A
Contact capacity		-	-
Mechanical life		10^6 times	10^6 times
Electrical life		10^5times	10^5times
Ambient temperature		-5ºC~+55ºC	-5ºC~+55ºC
Ambient humidity		45-85%RH	45-85%RH
Power consumption		2VA	2VA
