Printed Circuit Board 2 Layer Fr-4 3.5 Oz Electronics PCB
| Price: |
US $ 0.76/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-126-V1.26 |
| Final Foil External: |
3.5 Oz |
| Final Height Of PCB: |
1.0mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Blue |
| Colour Of Component Legend: |
White |
| Minimum Trace And Space: |
11.81 Mil/7.86 Mil |
| Minimum / Maximum Holes: |
0.425/3.5mm |
| Board Plating: |
0.0029" |
| Outline Dimension: |
0.0059" |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
| Brand: |
Iteq Material |
Product Description
Heavy Copper PCB FR-4 Tg175 3.5oz Printed Circuit Board Double Sided At 1.0mm Thick
Blue Solder Mask Applied For USB Charger
Commodity IntroductionThis is a type of FR-4 PCB for the application of USB Charger. It's a 2 Layer board at 1.0mm thick.
The base laminate is from ITEQ, Solder mask and silkscreen from Kuangshun. It's fabricated per
IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.
Parameters & Data Sheet| BOARD TYPE | |
| Number of Layers | Double sided PCB |
| Surface Mount Components | YES |
| Through Hole Components | YES |
| LAYER STACKUP | copper ------- 105 um(3 oz)+plate TOP layer |
| FR-4 1.0mm |
| copper ------- 105 um(3 oz)+plate BOT Layer |
| TECHNOLOGY | |
| Minimum Trace and Space: | 11.81 mil/7.86 mil |
| Minimum / Maximum Holes: | 0.425/3.5mm |
| Number of Different Holes: | 15 |
| Number of Drill Holes: | 940 |
| Number of Milled Slots: | 20 |
| Number of Internal Cutouts: | 0 |
| Impedance Control | no |
| BOARD MATERIAL | |
| Glass Epoxy: | FR-4, ITEQ IT-180 TG>175, er<5.4 |
| Final foil external: | 3.5 oz |
| Final foil internal: | 0 oz |
| Final height of PCB: | 1.0mm ±0.1 |
| PLATING AND COATING | |
| Surface Finish | Immersion Gold (22.4%) 2 micoinch over
100 microinch nickel |
| Solder Mask Apply To: | TOP, 12micron Minimum |
| Solder Mask Color: | Blue, KSM-S6189BL04, Kuangshun supplied |
| Solder Mask Type: | LPSM |
| CONTOUR/CUTTING | Routing, Fiducial Marks |
| MARKING | |
| Side of Component Legend | TOP |
| Colour of Component Legend | White, IJR-4000 MW300 |
| Manufacturer Name or Logo: | Marked on the board in a conductor and
leged FREE AREA |
| VIA | Plated through hole(PTH), Tented. |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" |
| Board plating: | 0.0029" |
| Drill tolerance: | 0.002" |
| TEST | 100% Electrical Test prior shipment |
| APPLICATION: | USB Charger, Power Supply 24V
Agilent Power Supply
Benchtop Power Supply
Scada Systems
24V Dc Power Supply |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
Fast PCB prototypes| Category | Fastest lead time | Stanardard lead time |
| 2 layer | 24 hrs | 4 days |
| 4 layer | 48 hrs | 5 days |
| 6 layer | 72 hrs | 7 days |
| 8 layer | 96 hrs | 9 days |
| 10 layer | 120 hrs | 11 days |
| 12 layer | 120 hrs | 12 days |
| 14 layer | 144 hrs | 15 days |
| 16-20 layer | Depends on specifications |
| 20 layer above | Depends on specifications |
Frequently Asked Questions
Do you sell quick turn (fast PCB) prototypes?
Yes. We offer PCB prototypes and quick turn prototypes. The quickest time is 24 hours for
double sided and 5 days for 4 layer PCB. The disadvantage of quick turn is high cost.
