Prototype PCB 4 Layers Circuit Board Fr-4 Tg 170
| Price: |
US $ 1.05/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-657-V6.57 |
| Final Foil External: |
1.0 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
None |
| Colour Of Component Legend: |
None |
| Mininum Trace (Mil): |
7.87 Mil |
| Minimum Gap(Mil): |
5.9 Mil |
| Warpage: |
0.56% |
| RoHS Required: |
Yes |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company Profile
Bicheng Enterprise Limited offers single sided / double sided and multilayer circuit boards.
We have been serving PCB electronics industry in Shenzhen, China since 2003.
Our advantages
* Your satisfied source to buy printed circuit boards (PCBs)
* All PCBs are 100% tested (flying probe or fixture test)
* Free panelizing
* Special price for partners
* On time delivery
* No minimum order quantity
* Worldwide shipping, door to door service
Our products
* PCB Prototypes and PCB Production
* Rigid PCB Fabrication
* Flexible PCB (FPC)
* PCB up to 32 layers
* RoHS complaint, Lead free PCBs
* Material: FR-4, High Tg (Tg170, Tg180), RO4350B, RO4003C, Polyimide
* Controlled Impedance
* Surface finish: HASL, HASL lead free, Immersion tin, Immersion silver, Immersion gold, gold
finger
* Blind vias
* 3 days to 4 weeks lead time
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Technology Information
ITEQ Laminate/ Prepreg : IT-180ATC / IT-180ABS
IPC-4101C Spec / 99 / 101 / 126
LAMINATE( IT-180ATC)| Property | Thickness<0.50 mm | Thickness>=0.50 mm | Units | Test
Method |
| [0.0197 in] | [0.0197 in] |
Typical
Value | Spec | Typical
Value | Spec | Metric | IPC-TM
-650 |
| (English) | (or as noted) |
Peel Strength,
minimum | | | | | N/mm | 2.4.8 |
A.Low profile
copper foil and
very low profile
copper foil - all
copper weights
> 17mm [0.669
mil] | | | | | (lb/inch) | 2.4.8.2 |
B.Standard
profile copper
foil | 0.88 (5.0) | 0.70 (4.00) | 0.88 (5.0) | 0.70 (4.00) | | 2.4.8.3 |
1.After
Thermal
Stress | | | | | | |
2.At 125°C
[257 F] | | | | | | |
3. After
Process
Solutions | 1.23 (7.0) | 0.80 (4.57) | 1.40 (8.0) | 1.05 (6.00) | | |
| | 1.05 (6.0) | 0.70 (4.00) | 1.23 (7.0) | 0.70 (4.00) | | |
| | 1.05 (6.0) | 0.55 (3.14) | 1.23 (7.0) | 0.80 (4.57) | | |
Volume
Resistivity,
minimum | | | | | MW-cm | 2.5.17.1 |
| A. C-96/35/90 | 3.0x1010 | 106 | -- | -- |
B. After
moisture
resistance | -- | -- | 3.0x1010 | 104 |
C. At elevated
temperature
E-24/125 | 5.0x1010 | 103 | 1.0x1010 | 103 |
Surface
Resistivity,
minimum | | | | | MW | 2.5.17.1 |
| A. C-96/35/90 | 3.0x1010 | 104 | -- | -- |
B. After moisture
resistance | -- | -- | 3.0x1010 | 104 |
C. At elevated
temperature
E-24/125 | 4.0x1010 | 103 | 4.0x1010 | 103 |
Moisture
Absorption,
maximum | -- | -- | 0.12 | 0.8 | % | 2.6.2.1 |
Dielectric
Breakdown,
minimum | -- | -- | 60 | 40 | kV | 2.5.6 |
Permittivity
(Dk, 50%
resin content) | | 5.4 | | 5.4 | -- | |
(Laminate &
Laminated
Prepreg) | | | |
| A. 1MHz | 4.4 | 4.4 | 2.5.5.9 |
| B. 1GHz | 4.4 | 4.4 | |
| C. 2GHz | 4.2 | 4.3 | 2.5.5.13 |
| D. 5GHz | 4.1 | 4.1 | |
| E. 10GHz | 4 | 4.1 | |
Loss Tangent
(Df, 50% resin
content) | | 0.035 | | 0.035 | -- | |
(Laminate &
Laminated
Prepreg) | | | |
| A. 1MHz | 0.015 | 0.014 | 2.5.5.9 |
| B. 1GHz | 0.015 | 0.015 | |
| C. 2GHz | 0.015 | 0.015 | 2.5.5.13 |
| D. 5GHz | 0.016 | 0.016 | |
| E. 10GHz | 0.017 | 0.016 | |
Flexural
Strength,
minimum | | | | | N/mm2 | 2.4.4 |
A. Length
direction | -- | -- | 500-530 | 415 | (lb/in2) |
| | -- | -- | (72,500-76,850) | -60,190 | |
B. Cross
direction | -- | -- | 410-440 | 345 | |
| | -- | -- | (59,450-63,800) | -50,140 | |
Arc
Resistance,
minimum | 125 | 60 | 125 | 60 | s | 2.5.1 |
Thermal
Stress
10 s at
288°C
[550.4F],
minimum | | | | | Rating | 2.4.13.1 |
| A. Unetched | Pass | Pass
Visual | Pass | Pass
Visual |
| B. Etched | Pass | Pass
Visual | Pass | Pass
Visual |
Electric
Strength,
minimum | 45 | 30 | -- | -- | kV/mm | 2.5.6.2 |
(Laminate &
Laminated
Prepreg) |
| Flammability, | V-0 | V-0 | V-0 | V-0 | Rating | UL94 |
(Laminate &
Laminated
Prepreg) |
Glass
Transition
Temperature
(DSC) | 175 | 170
minimum | 175 | 170
minimum | ˚C | 2.4.25 |
Decomposition
Temperature | -- | -- | 345 | 340
minimum | ˚C | 2.4.24.6 |
| (5% wt loss) |
X/Y Axis
CTE (40ºC
to 125ºC) | -- | -- | 10--13 | -- | PPM/˚C | 2.4.24 |
| Z-Axis CTE | | | | | | 2.4.24 |
| A. Alpha 1 | -- | -- | 45 | 60
maximum | PPM/˚C |
| B. Alpha 2 | -- | -- | 210 | 300
maximum | PPM/˚C |
C. 50 to
260 Degrees
C | -- | -- | 2.7 | 3.0
maximum | % |
Thermal
Resistance | | | | | | 2.4.24.1 |
| A. T260 | -- | -- | >60 | 30
minimum | Minutes |
| B. T288 | -- | -- | >30 | 15
minimum | Minutes |
CAF
Resistance | -- | -- | Pass | AABUS | Pass/Fail | 2.6.25 |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
