PVC 3.0mm Fiber Optic Patch Cord St to St 50 / 125 Multimode Cable

Name: PVC 3.0mm Fiber Optic Patch Cord St to St 50 / 125 Multimode Cable
Brand: all-electronics-online.com
SKU: 808289845
Availability: InStock
Rating: 4.9 (38 reviews)

Price:	US $ 1.25/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	Patch Cord Indoor
Application:	Probe
Connection Structure:	FC-MTRJ
Certification:	Reach
Type:	Single More or Multimode
Brand:	OEM or Tw-Scie
Sheath Material:	LSZH,PVC,

Product Description

PVC 3.0mm Fiber Optic Patch Cord ST to ST 50/ 125 Multimode Cable

Quick Details

Fiber Optic Accessories
ST to ST 62.5/125 Multimode
62.5 / 125 um Multimode
2.0 or 3.0mm OD
Orange Color
PVC Material
PE Bag / Carton
Fiber Optic Patch Cord
ISO, CE, RoHS, UL

Description

A fiber optic patch cord is a fiber optic cable capped at either and with connectors that allow it to be rapidly and conveniently connected to CATV , an optical switch or other telecommunication equipment. Its thick layer of protection is used to connect the optical transmitter , receiver and the terminal box.

Fiber optic patch cords are characterized by:

High return loss
Low insertion loss

Good repeatability

Good interchange

Excellent environmental adaptability

Specifications: PVC 3.0mm Fiber Optic Patch Cord
Connector Type	ST/ST Multimode
Connector Type	ST/PC Multimode
Zipcord Cable	50 / 125 um Multimode
Cable Jacket ( OD: 3.0mm )	Orange Color , PVC Material
Shrink Tube

Perfomance
Insertion Loss	< 0.5 dB
Fiber Extention	-0.05um < H < + 0.05um
Ferrule End - face Radius	10 < R < 30mm
Apex Offset	< 50 um
Increase in insertion loss after 500 mating	0.2 dB Max
Operation Temperature	-20ºC to +70 ºC
Storage Temperature	-20ºC to +80 ºC
Humidity (non- condensing)	95% RH

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

*A, Incoming material inspected by QC.

*B, Manufacturing Process Control

*C: Workers trained daily/weekly/monthly

*D: Work instructions manual at each work station

*E: 5S system implemented

*F: Machine maintenance procedure

*G: Quality Control and Final Inspection

The QC staff will check the material, process product and final product according to the specification or test procedure.

2, Our R&D efforts center on reinforcing and developing element technologies needed to support the future growth and success for customers.

3, We know customers have urgent needs.

We are skilled at effective communication to interact with customers.

In order to provide prompt service, we can answer for you 7*24 hours.

4, We can Quickly and professionally answer for the inquire

5, More than 1000 kinds of cable, connectors and assembles can be produce and organized from us

6, Intime delivery

DONGGUAN TW-SCIE Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication

Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.

The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.

The main products of our enterprise are:

Optical fiber, optical cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.

All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.
