PVC Insulated Copper Condcutor Earth Cable Yellow/Green

Name: PVC Insulated Copper Condcutor Earth Cable Yellow/Green
Brand: all-electronics-online.com
SKU: 736911725
Availability: InStock
Rating: 5 (61 reviews)

Price:	US $ 0.7-0.8/Meter
Trade Terms:	FOB,CIF
Min Order:	100/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	H07V-R, NYA, BV
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
No.Cores:	1
Jacket:	Non-Sheathed
Nominal Section:	1.5-400mm2
Rated Voltage:	450/750V
Laying Place And Requirement:	Fixed Laid Indoors,Conduits etc
Type:	Insulated
Conductor Type:	Stranded
Application:	Electrical Equipments,Building Wire
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	CCC

Product Description

Pvc insulated copper condcutor earth cable yellow/green

1. Brief construction

1) Conductor: Copper, stranded
2) Insulation: PVC
3) Number of cores: Single core
4) CCC, ISO9001
5) Other special characteristics: Design and manufacture according to the requirements of customers
6) Type of cable: H07V-R, NYA, BV.

2. Application

PVC insulated wires is suitable for laying at the fixed places. It is widely used in connecting of power device, lighting, daily electrical appliance, instrument etc. With AC rated voltage up to and including 450V/750V(U0/U).

3. Standard

The product implement the standards GB/T5023, equivalent to IEC60227. And it can also be made c omplying with ASTM, DIN, BS standards etc.
In addition, we can design and manufacture the products as the requirements of customers.

4. Service performance
1) Rated voltage: 450/750V.
2) Long-term working temperature: Not be higher than 70° C.
3) When laying the cable, the ambient temperature should not lower than 0° C.
4) Minimum bending radius: Bending radius≥ 4D as cable overall diameter≤ 25mm; Bending radius≥ 6D as cable overall diameter>25mm.

The company is set Branch, engineering, trade and an integrated enterprise, the main production: Wire and cable, instrument of the three categories of over 500 varieties of more than 2000 specifications. The company provides the following products for your selection and welcomed the use of its main products are: WR series thermocouple, WZ series of thermal resistance, bimetal thermometers, gauges, intelligent digital regulator controllers, temperature converters, display and power cable special cables, control cables, electrical wire and cable equipment communication cables, thermocouple wire compensation, compensation cable and high-temperature fluorine plastic compensation wire, cable, silicone rubber control cables, overhead cables, ACSR and aluminum cables, etc...

The company attaches great importance to science and technology development and technological progress, in December 2000 introduction of a special cable production line, self-regulating heating cable series is currently the most favored by the majority of users of high-tech products. The Company and the National Institute of more than 10 projects to establish a cooperative relationship, sales network throughout the country.

We will adhere to the "technology works, good faith, " the purpose and dedication to providing quality products and excellent service. Welcome patrons, the inquiry.
