PVC Insulation Electrical Control Cable

PVC Insulation Electrical Control Cable
Price: US $ 1-99/Meter
Min Order: 500/Meter
Pay Type: L/C,T/T
Prod Model: KVV, KVVR
Rated Voltage: 450/750V
Refer Standard: IEC60502
Type: Insulated
Conductor Type: Stranded
Conductor Material: Copper
Insulation Material: PVC
Certification: CCC
Application: System Connection Wire
Range Of Application: System Connection Wire
Brand: Jl

Product Description

PVC Insulation Electrical Control Cable

1 Application

Suitable for System connection wire of control,signal,protection or measuring for rated voltage up to
and including 450/750V.

2 Standard

The control cable can be produced according to the standard GB9330-1988,IEC60227(60502,60332),DIN, BS, and our factory can also manufacture the cables in accordance with other standards.3 Application Properties
4 Description

Type

Name

KVV

Copper conductor PVC insulated PVC sheathed control cable

KVVP

Copper conductor PVC insulated PVC sheathed braiding screened control cable

KVVP2

Copper conductor PVC insulated PVC sheathed copper tape screened control cable

KVV22

Copper conductor PVC insulated PVC sheathed steel tape armored control cable

KVV32

Copper conductor PVC insulated PVC sheathed fine steel wire armored control cable

KVVR

Copper conductor PVC insulated PVC sheathed flexible control cable

KVVRP

Copper conductor PVC insulated PVC sheathed braiding screened flexible control cable

KYJV

Copper conductor XLPE insulated PVC sheathed control cable

KYJVP

Copper conductor XLPE insulated PVC sheathed braiding screened control cable

KYJVP2

Copper conductor XLPE insulated PVC sheathed copper tape screened control cable

KYJV22

Copper conductor XLPE insulated PVC sheathed steel tape armored control cable

KYJV32



Copper conductor XLPE insulated PVC sheathed fine steel wire armored control cable

KYJVR

Copper conductor XLPE insulated PVC sheathed flexible control cable

KYJVRP

Copper conductor XLPE insulated PVC sheathed braiding screened flexible control cable

Jiangsu Jinling Special cable Co., Ltd. Was founded in 1998. It is a comprehensive cable enterprise integrating research, development, production, sales and service. The company is located in nanjing, jiangsu province, the industrial concentration area, with convenient transportation. The registered trademark of the company is "Yong Heng", which covers an area of 30000 square meters, with a building area of 80, 000 square meters and annual production capacity of USD 190 million. The company has 159 employees, including 48 professional and technical talents.

The company is a high-tech manufacturing enterprise with high technical content, complete quality management system and advanced inspection methods. The company has the domestic first-class production line and testing equipment, the technical force is strong. Main products are: Medium and low Voltage power cables, control cables, instrument cables, Aluminum Alloy cable, bare conductor, Aerial bundled cable, electrical wire, compensation cable, high temperature resistant cable, fire resistant cable, fire retardant cable, wind cable, Marine cable, anti-corrosion, waterproof cable., are widely used in electric power, metallurgy, petroleum, chemical industry, automobile, papermaking, coal mine, shipbuilding, ports, lifting, building materials, pharmaceutical and other industries. Company strictly according to GB, IEC, CE, As, UL, VDS standards, and pass ISO9001 certification, to provide customers with a variety of specifications of wire and cable.

Excellent quality, perfect management and first-class service is our permanent puisuit.
