Hangzhou DAYTAI Network Technologies Co., Ltd. >> RCA Compression Connector for Rg59 RG6 Coaxial Cable

RCA Compression Connector for Rg59 RG6 Coaxial Cable

RCA Compression Connector for Rg59 RG6 Coaxial Cable
Price: US $ 0.02-0.05/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 500/Piece
Pay Type: L/C,T/T,Paypal,Western Union
Prod Model: RCA Compression Connector
Bandwidth: 0~1000MHz
Plating: Nickel
Length: 18mm or 20mm
Impedance: 75ohm
OEM/ODM: Welcome
Brand: Daytai
Interface Type: Rg59 RG6 Compression Connector
Type: RCA Connector

Product Description

Specifications
RG6 RCA Compression Connector, CATV Connector, suitable for RG59, RG6 coaxial cable.

Description of RG6 RCA Compression Connector
RG59/RG6 RCA compression connector, CATV Connector, suitable for RG59, RG6 coaxial cable.

Features of RG6 RCA Compression Connector
Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
Designed to be watertight for outdoor applications
Offer excellent RFI shielding properties
Easy-grip free-spinning nut for fast installation and installer comfort
For standand RG6/RG59
Frequency Range DC~1000MHz
Working Voltage  335V max
Withstand Voltage  750V rms
Contact resistance
Center Contact ≤ 10 mΩ
Outer Contact   ≤ 5 mΩ
Insulation resistance  ≥ 1000 MΩ
Durability(mating)  ≥500(cycles)
Temp.range -50~+60°C
