Red and Black Color Flexible Transparent Speaker Cable

Name: Red and Black Color Flexible Transparent Speaker Cable
Brand: all-electronics-online.com
SKU: 665237802
Availability: InStock
Rating: 4.4 (53 reviews)

Price:	US $ 2/Piece
Trade Terms:	FOB,CIP,CPT
Min Order:	100/Roll
Pay Type:	L/C,T/T,Paypal,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	Speaker Cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Conductor:	Bare Copper or Tinned Copper
Insulation:	PVC
Shape:	Figure 8
Application:	Speaker
Certification:	VDE
Connector:	RCA
Species:	Speaker Cable
Color:	Transparent
Type:	Speaker Cable

Product Description

Speaker cable

Type 1: Flat Flexible Twin Stranded Bare Copper

PVC Insulated (Black & Red Color)

----------------------------------------------------------------

Type 2: Flat Flexible Stranded Tinned & Bare Copper

Transparent PVC insulated

Application:

Audio analogical signals

Used for installation in normal Indoor environments

Long distance high signal purity

Conductor

Stranded Bare Copper

Stranded Bare Copper &Tinned Copper

Insulation:

PVC (Black & Red Color) or PVC Transparent

Temperature Range:

In motion -10ºC till +70ºC

Nos. of Cores & Section(mm2)	Dimension mm	Insulation Resistance MOhm/KM	Operating Voltage V a.c.	Weight Kg/100mt
2×0.50	2.40×4.80	200	250	2.1
2×0.75	2.50×5.00	200	250	2.9
2×1.00	2.60×5.20	200	250	3.2
2×1.50	2.70×5.60	200	250	4.4
2×2.50	3.50×7.00	200	250	7
2×4.00	4.60×9.20	200	250	11

item	specification	Outer diameter
2*0.35	11/0.20*2C	2.0*4.0
2*0.5	16/0.20*2C	2.2*4.4
2*0.75	24/0.20*2C	2.5*5.0
2*1.0	32/0.20*2C	3.0*6.0
2*1.5	48/0.20*2C	3.5*7.0
2*2.0	64/0.20*2C	3.8*7.6
2*2.5	80/0.20*2C	4.0*8.0
2*4.0	80/0.25*2C	4.5*9.0
2*0.35	44/0.10*2C	2.0*4.0
2*0.5	64/0.10*2C	2.2*4.4
2*0.75	332/0.102C	2.5*5.0
2*1.0	719/0.102C	3.0*6.0
2*1.5	727/0.102C	3.5*7.0
2*2.0	736/0.102C	3.8*7.6
2*2.5	746/0.102C	4.0*8.0
2*4.0	773/0.102C	4.5*9.0
10AWG	724/0.202C	5.0*10
12AWG	105/0.20*2C	4.2*8.4
14AWG	70/0.20*2C	3.8*7.6
16AWG	65/0.16*2C	3.2*6.4
18AWG	41/0.16*2C	3.0*6.0
20AWG	26/0.16*2C	2.6*5.2
22AWG	16/0.16*2C	2.4*4.8
24AWG	10/0.16*2C	2.0*4.0
