Ring Type Current Transformer (RCT-25)

Name: Ring Type Current Transformer (RCT-25)
Brand: all-electronics-online.com
SKU: 704730105
Availability: InStock
Rating: 4.3 (133 reviews)

Price:	US $ 1.5-2.5/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	RCT-25
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Rct-60
Class:	0.5/1.0
Current Capacity:	300A-1200A
Maximun Voltage:	0.66kv
Type:	Current Transformer
Phase:	Three

Product Description

RCT current transformer series:

Model RCT series current transformer are available for connecting with cable, and also available for connecting with bus bar

RCT tecnicial specifications:
Primary current: 30A-3000q
Secondary current: 5A/1A
Standard approval: IEC44-1
Maximum voltage: 0.66kv
Frequency: 50/60Hz
Class: 0.5/1.0
Rated load: 15VA
Short time thermal current: Ith=60*ih
Rated security coefficient: Fs<5

Model	Primary/Second (A)
RCT-25	15/5, 20/5, 30/5, 40/5, 50/5, 60/5, 75/5, 100/5
RCT-35	30/5, 50/5, 60/5, 80/5, 100/5, 120/5, 150/5, 200/5, 250/5, 300/5
RCT-60	300/5, 400/5, 500/5, 600/5, 800/5, 1000/5, 1200/5
RCT-90	800/5, 1000/5, 1200/5, 1500/5, 1600/5
RCT-110	1000/5, 1200/5, 1500/5, 1600/5, 2000/5, 2500/5, 3000/5
