RO4350b (0.254mm) 18 Layer PCB Circuit Board Chip on Board
| Price: |
US $ 1.03/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-664-V6.64 |
| Final Foil External: |
1.0oz |
| Final Height Of PCB: |
1.0mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Green |
| Colour Of Component Legend: |
White |
| Mininum Trace (Mil): |
5.0 Mil |
| Minimum Gap(Mil): |
4.9 Mil |
| RoHS Required: |
Yes |
| Warpage: |
0.21% |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company ProfileBicheng Enterprise Limited offers single sided / double sided and multilayer circuit boards.
We have been serving PCB electronics industry in Shenzhen, China since 2003.
Our advantages
* Your satisfied source to buy printed circuit boards (PCBs)
* All PCBs are 100% tested (flying probe or fixture test)
* Free panelizing
* Special price for partners
* On time delivery
* No minimum order quantity
* Worldwide shipping, door to door service
Our products
* PCB Prototypes and PCB Production
* Rigid PCB Fabrication
* Flexible PCB (FPC)
* PCB up to 32 layers
* RoHS complaint, Lead free PCBs
* Material: FR-4, High Tg (Tg170, Tg180), RO4350B, RO4003C, Polyimide
* Controlled Impedance
* Surface finish: HASL, HASL lead free, Immersion tin, Immersion silver, Immersion gold, gold
finger
* Blind vias
* 3 days to 4 weeks lead time
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Technology Information
Design For Manufacture| Serial NO. | Procedure | Item | Manufacturing capability |
Large
volume
(S<100 m²) | Middle
volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 84 | Special tolerance | Board thickness
of flying probe
test | 0.6-4.0mm |
| 85 | Panel size of
flying probe
test | Size≤900X600mm,Small size can be
compensated through manufacturing
procedure |
| 86 | Panel size of
fixture test
method | Size≤460X380mm, Small size can be
compensated through manufacturing
procedure |
| 87 | Board thickness
of fixture test
method | 0.4-6.0mm |
| 88 | Tolerance of
press-fit hole | ±2mil |
| 89 | Tolerance of
NPTH | ±2mil |
| 90 | Tolerance of
PCB thickness | 1.0mm≥PCB thickness, Tolerance ±0.1mm;
1.0mm≤PCB thickness, Tolerance±10% |
| 91 | Tolerance of
depth of
countersunk hole | ±0.2mm |
| 92 | Depth tolerance
of blind slot | ±0.2mm |
| 93 | Maximum
shipment size | Size≤1200X600mm(Double side, no test
required) |
| 94 | Size≤1000X600mm( Multilayer, no test
required) |
| 95 | Minimum
shipment size | 10X10mm |
| 96 | PCB thickness
of HASL | 0.8-3.0mm(Hole less 0.5mm should be use
via-plug or mask-tent ) |
| 97 | HASL PCB Size | Size≤600X460mm |
| 98 | PCB thickness | 0.15-7.0mm |
| 99 | Depth of V
groove | 0.8-3.2mm |
| 100 | Distance of non-
continuous v-
groove | ≥7mm |
| 101 | Max. drill diameter | Size≤6.5mm (Counterbore or router will be
used for holes more than 6.5mm, Min.
tolerance ±0.1mm ) |
| 102 | Max. countersink
diameter | Size≤6.5mm Countersink can be used
counterbore drill or router) |
| 103 | Distance of
Bevel | Size≥11mm | Size≥5mm | Size≥5mm |
| 104 | Thickness of
peelable mask | 0.2-1.5mm ±0.15mm |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
