| Prod Model: |
S2900 frequencyinverter |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Input Voltage: |
380V-440V |
| Output Voltage: |
380V-440V |
| Output Frequency: |
0.1-400Hz |
| Control Type: |
Vector Control |
| Loading: |
Heavy Loading |
| Output Current: |
17A-640A |
| Application: |
High Frequency Converter Transducer |
| Output Type: |
Triple |
| Principle Of Work: |
V/F Control Transducer |
| Switch Mode: |
PWM Control |
| Main Circuit Type: |
Voltage |
| Brand: |
Machtric Inverter |
Product Description
S2900 series Transducer Frequency inverter
Features:
Intelligent input terminal:
Speed shift can be present in 8th phase ,the first/second acceleration and deceleration time shift ,prohibition of acceleration and deceleration ;external interrupt input ;inching operation ;increasing/decreasing frequency setting terminal
Intelligent output terminal:
During running ,frequency arrival and output, non-zero speed ,over-torque output, low-voltage detection of external interrupt indication, operating mode indication, abnormal malfunction output, and external abnormal interrupt
Built-in Function :
Upper and lower limits setting of output frequency ,instantaneous restart for power failure ,restart for abnormal malfunction ,automatic voltage output regulation ,anomaly records parameter hold ,parameters reset to the factory defaults ,prohibition of reversion ,over-current stall prevention ,over-voltage stall prevention ,electronic thermal relay
Protection Function:
protection of inverter unit phase ,accelerated over-current, decelerated over current ,constant-speed over-current, acceleration over-voltage, decelerated over-voltage ,constant-speed over-voltage, bus under-voltage failure ,motor overload, Inverter overload, open-phase at output side(75kw+models),rectification module overheating, overheating fault of inverter module, external fault, communication fault ,current detection fault ,motor self-learning fault ,EEPROM operational fault, PID feedback disconnection fault ,braking unit fault
Safety self-checking function :
electrifying of the inverter, complete safety self-checking of software and hardware by the system
Standby display function:
there are totally 9 parameters of halt mode which can be chosen to display or not ;there are totally 14 parameters of operation mode which can be chosen to display or not
V/F curve setup control /vector control function
Function of energy-saving running option :
during no-load or light-load running of motor ,adjust the output voltage properly by detecting load current to achieve automatic energy saving .(This function is especially effective on the load of blower or pump )
Function of automatic fault detection and recording :
Detection function of the previous two faults' types ;recording function of the previous fault's type ,voltage, current, running frequency, output/input terminal state .
About Us:
We are professional manufacturer under Sanch organization from Taiwan supplying with factory automation products like variable frequency inverter (AC drive),
circular knitting machine controller, power controller and total solution for industrial electric control system as client's demands
Why choose our frequency inverter?
1.Easy operating system.--- easy but effective software ,gentle touch achieve.
2.Stable performance--- best famous company ensure the quality all the time.
3.Excellent after sales service--- never leave you along.
4.Fast delivery --- safety delivery ,we look after it all the time
More information ,pls contact with Alice.
Quanzhou Machtric Automation Equipment Co., Ltd., together with three leading enterprises and several affiliated organizations in China and Taiwan has been established to supply "Total Project Solutions" in Industrial Automation.Sanch is geared to integrate the development, manufacture and systems engineering for local and international clients alike.
Our professional teams of engineering, product development, manufacturing and integration staff, devote themselves to the development and application of motor, electric, electronic, microelectronic, information and control technology.
We continue to maintain close co-operation with scientific research institutions both at home and abroad, in order to provide "intelligent" products that not only offer the best solutions, but also have a "humanized" approach to functionality.
At present, our manufacturing capacity is over 100 thousand devices per annum.
This includes products such as:
A/C Frequency Inverters (INVERTER)
Thyristor power controller
Circular knitting machine
Intelligent Control Instruments
Peripheral equipment for Industrial Process Control (IPC)
Microcomputer Controllers for various applications and many others.
In order to service the Chinese market, we have already established dozens of marketing, distribution agents and service organizations, to cover the Northern, Eastern, Central and Southern areas.A Pathway Management System and CRM Customer Relationship Centre with high-efficiency logistic and linkage service has also been established.
SANCH have already applied their range of products and services to the following industries;Textile, dye, ceramic, transportation, building, metallurgy, chemical, light, military ---etc.
SANCH philosophy is to continually improve the electric management platform to account for all facets of applications, thus maximising the competitiveness of technology, quality, service and efficiently in accordance with the principle of satisfying our customers and creating excellent products.
SANCH actively promote a philosophy of, maximising production outputs and yet minimizing energy consumption, using modern technological developments.
Our goal is to achieve "Automation---Energy Saving---Green World", and we will try our best to improve the environment and society as a whole.
