Safety Magnetic Contactor, Model Src Magnetic Starter

Prod Model:	SRC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Src
Circuit:	AC 50Hz or 60Hz
Rated Voltage(V):	550V
Name:	Magnetic Starter

Product Description

Application
SRC Magnetic Starter is mainly applied to circuit of AC 50Hz or 60Hz, voltage up to 550V for far distance making and breaking circuit and frequently starting and controlling motor. It has the features of small volume, light weight, low power consumption, high efficiency, safe and reliable performace etc.

Type	Rated Power (kW)					Rated Current (A)			AC1 Duty
	1 Pole Motor		AC3 Duty			AC3 Duty
	110V	220V	200V~ 220V	380V~ 440V	500V~ 550V	200V~ 220V	380V~ 440V	500V~ 550V	A
SRC-9B	0.4	0.8	2.5	4	4	11	9	7	20
SRC-12B	0.5	1	3.5	5.5	7.5	12	12	12	20
SRC-18B	0.75	1.5	4.5	7.5	7.5	18	18	13	25
SRC-22B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-32B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-40B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-50B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-65B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-75B	0.9	1.8	5.5	11	15	22	22	22	32
SRC-85B	0.9	1.8	5.5	11	15	22	22	22	32
