| Prod Model: |
Capaciitor |
| Type: |
High Frequency Ceramic Capacitor |
| Application: |
High Voltage |
| Package Type: |
Through Hole |
| Capacitance: |
>100uf |
Product Description
Environmental conditions
1, place of use: indoors or outdoors.
2, ambient temperature: -25 ºC ~ + 50 ºC.
3, Altitude: not exceed 2000m.
4, the installation site should run no harmful gases or vapors, no severe mechanical vibration, conductive or explosive dust.
Product Specifications
1, Rated frequency: 50 Hz / 60 Hz.
2, rated voltage: 0.23 kV ~ 2kV.
3, Loss: (tgδ) ≤0.05%.
4, capacitance tolerance: 0 to + 10%.
5, overload:
Allow overvoltage 1.1Un in each 24h 8h (system voltage regulation and fluctuations);
Allow overcurrent run continuously at 1.3In.
6, the maximum load: 1.35Qn stable operation (caused by over-voltage and harmonics).
7, built-in discharge resistors within 1 ~ 3min after power capacitor discharges to 50V or less.
8, product performance standards: GB12747, IEC60831.
Main Features
1, silver-zinc plated trapezoidal thickened edge of the capacitor capacitance with good self-healing and stability.
2, the unique gold spray process so that the capacitor has a good resistance to surge capacity.
3, BKMJ pure dry-type epoxy resin infusion device structure, the internal unit filled with an insulating harmless mineral filler particles to avoid the explosion of the capacitor, may burn and pollute the environment.
4, BSMJ type with sealing wax overall perfusion tank capacitor, its internal overpressure protection in the event of failure of the capacitor can be reliably isolated from the grid, to ensure that products do not leak, do not pollute the environment.
Ningbo Ville Electric Co., Ltd. One of wholly owned subsidiaries of VILLE INDUSTRY, It was invested by VILLE INDUSTRY, It is a well-know listed company in China specialized in R&D of electric power technology, equipment manufacturing and engineering services specialized in research, development, production of transformer and high voltage & low voltage electrical power equipment
Our Transmission and distribution companies can provide with whole solution for transformer substation and switch substation trunkey project!
The rated voltage from 11kV up to 132kV.
It locates in Hi-technical enterprise R & D center zone of Ningbo, Zhejiang province, which is one of the well-know coastal city in China. Its professional engaged in power substation, power plant project and electrical power complete equipments.
Working field: Manufacturing, engineering, designing, executing and commissioning for HV and LV electrical products. Turnkey substation from 11KV to 132KV.
Our transformer factory main working is visiting end user's site do measure and reseach before designe, and providing economic transformer solution for customer. Engineering, manufacturing, executing, commissioning and repairing for different kind of transformer (04kv -500kv ).
The products are mainly used in Steel plant; Power - Fossil fuel plant, Nuclear power plant, Railway, Subway and Airport. Wind power generation; Hydroelectric plant engineering; International power generation plant; Power substation transmission and distribution; Residential housing estate power distribution system and so on.
Transformer factory Product includes:
Three phase double (three)- winding power transformer, generator power transformer, auto power transformer, rectifier transformer for each industry, furnace transformer, movable transformer, traction transformer and reactor, power plant auxiliary and standby transformers, transformers for substations of backbone and distribution networks. Transformer for metallurgical companies etc.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide transformer supplier"
Supply the guide drawings and installation manuals information directions on the method of handling, storage, mounting and erection of transformers.
Power equipment application:
Power-fossil fuel plant, Steel plant, Infrastructure- railway, international generation, substation, hydropower station, wind power substation, transmission and distribution.
We has excellent experience and good capacity in complete projects equipments in Generation, Substation, Transmission and Distribution from 400V-330kv, especially in Power plant, Substation construction and Transmission line, including of design, complete equipment, installation, Commissioningand after-sales service, and also design the complete Electrical Solutions according to customer's demand. We are mainly services to International State Power Board, Power Construction Contractor, Power Project Contractor, Factories and the Electric Power Project in the world.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide electrical equipment supplier
