Sid Residual Current Circuit Breaker

Prod Model:	SID
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Breaking Capacity:	High Voltage Circuit Breakers
Operation:	Electric Type
Speed:	High-Speed Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Poles Number:	2
Structure:	Moulded Case Circuit Breaker

Product Description

1.Application

SID RCCB is in conformity with the standard of IEC61008. The RCCB can cut off the faultcircuit immediately on the occasion of shock hazard or earth leakage of trunk. Thus, it is suitableto avoid the shock hazard and fire caused by earth leakage.The RCCB is mainly suitable for use in varieties of plants and enterprises, building construction1 phase 230V and 3 phase 400V 50/60Hz. RCCB is not suitable for use on DC pulse system.

2.Specification

Number of Poles	2P, 4P
Rated Current (A)	16, 20, 25, 40, 50, 63
Rated Residual Operating Current (In)(mA)	30, 100, 300, 500
Rated Voltage (V)	AC 230/240
	AC 400/415
Residual Operating Current Scope	0.5In~In
Residual Current Off-time	≤0.3S
Short Circuit Capacity (Icu)	6000A
Endurance(times)	4000
Protection Degree	IP20
