Single Core PVC Wire 4mm2

Name: Single Core PVC Wire 4mm2
Brand: all-electronics-online.com
SKU: 711016002
Availability: InStock
Rating: 4.7 (124 reviews)

Price:	US $ 0.05/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BV
Insulation Color:	Red/Black/Black/Green/Yellow
Type:	Insulated
Conductor Type:	Stranded
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	CCC
Application:	Building
Range Of Application:	Building

Product Description

Single Core PVC Wire 4mm2
Product Details:

Type Insulated
Application POWER
Conductor Type Stranded
TWO COLOR WIRE YELLOW/GREEN
Insulation Material PVC
Conductor Material TO BE REQUIRED
Place of Origin Henan China
Brand Name YIFANG
Model Number BV, CU/PVC

mm2	Nos	Dia	Over Dia	Thickness	Overall dia
1.5	1	1.38	1.38	0.7	2.78
1.5	7	0.52	1.56	0.7	2.96
2.5	1	1.78	1.78	0.8	3.38
2.5	7	0.67	2.01	0.8	3.61
4	1	2.25	2.25	0.8	3.85
4	7	0.84	2.52	0.8	4.12
6	1	2.76	2.76	0.8	4.36
6	7	1.04	3.12	0.8	4.72
10	1	3.57	3.57	1.0	5.57
10	7	1.35	4.05	1.0	6.05
16	7	1.70	5.10	1.0	7.1
25	7	2.14	6.42	1.2	8.82
35	7	2.52	7.56	1.2	9.96
50	19	1.78	8.90	1.4	11.7
70	19	2.14	10.70	1.4	13.5
95	19	2.52	12.60	1.6	15.8
120	37	2.03	14.21	1.6	17.41
150	37	2.25	15.75	1.8	19.35
185	37	2.52	17.64	2.0	21.64
240	61	2.25	20.25	2.2	24.65
300	61	2.52	22.68	2.4	27.48

YELLOW GREEN PVC INSULTED CABLE USED FOR EARTHING WIRE

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
