Single-Phase Bridge Rectifier Modules

Name: Single-Phase Bridge Rectifier Modules
Brand: all-electronics-online.com
SKU: 663872721
Availability: InStock
Rating: 4.3 (141 reviews)

Price:	US $ 5-38/Piece
Trade Terms:	FOB
Min Order:	3/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	MDQ60-500A 600-2000V
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Vrrm:	600-2000V
Irrm:	10mA
Vfm:	1.4V
Ifm:	315A
Manufacturing Technology:	Discrete Device
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	Standard Export Packing
Application:	PWM Frequency Transformer,DC Power Supply
Model:	Mdq60-500A 600-2000V
Batch Number:	2016+
Brand:	Shnagjing

Product Description

Features
Electrical insulated for chip and base
International standard packaging
Excellent temperature characteristic
Easy to install and maintain
Low VFM

Typical Applications
Instrument's DC power supply
PWM frequency transformer
Input rectification power supply
DC motor field power supply
Switch power supply input rectification

Type	Id@Tc		VRRM	VFM@IFM		IRRM	IF(AV)	IF(RMS)	ITSM	Rjc	Tjm	Viso	Outline
Type	A	° C	V	V	A	mA	A	A	kA	° C/W	° C	V(AC)	Outline
MDQ60	60	100	600-2000	1.45	60	8	30	60	0.75	0.55	150	2500	M16/M17/M18
MDQ80	80	100	600-2000	1.37	80	8	40	70	1.00	0.32	150	2500
MDQ100	100	100	600-2000	1.43	150	10	50	86	1.50	0.24	150	2500
MDQ150	150	100	600-2000	1.37	230	10	75	106	2.00	0.15	150	2500	M19/M20
MDQ200	200	100	600-2000	1.40	315	10	100	157	2.50	0.15	150	2500
MDQ250	250	100	600-2000	1.38	380	8	125	200	2.75	0.14	150	2500
MDQ300	300	100	600-2000	1.40	450	10	150	240	2.90	0.13	150	2500	M21
MDQ400	400	100	600-2000	1.40	500	9	200	320	3.20	0.12	150	2500	M21
MDQ500	500	100	600-2000	1.43	600	10	250	400	3.50	0.10	150	2500	M22
